XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
Parts List – SMX 4000 and 5000 - Y-Axis Drive Assembly (Figures 24-26)
ITEM
P/N
DESCRIPTION
QTY
1
H-026-A
SCREW
3
2
H-026-B
SCREW
3
3
H-031-8
GIB
1
4
H-032-8
ALUMINUM PLATE
4
5
H-034-8B
SADDLE – SMX 4000
1
H-034-14B
SADDLE – SMX 5000
1
6
H-056
NUT
1
7
H-060
BEARING COVER
1
8
H-067-8
MACHINE BODY
1
9
H-067-12A
MACHINE BASE
1
10
H-075
FIXED HOLDER OF COOLANT NOZZLE
1
11
H-102-8
SCREW
6
12
H-103
ADJUSTING BLOCK
6
13
H-106-8
GIB SEAT
1
14
H-107-8
GIB SEAT
1
15
H-108-3
GIB
2
16
H-124-7B
ELECTRIC DEVICE BOX
1
17
H-165-8
CONNECTION PIPE
1
18
H-166-14B
FRONT COVER – SMX 4000
1
H-166-14C
FRONT COVER – SMX 5000
19
H-170-8
WASHER
6
20
H-173-8A
COVER
1
21
H-237-8
COVER
1
22
H-237-9
COVER
1
23
H-239
OIL NETWORK
2
24
H-239-10
OIL NETWORK
2
25
H-254
OIL NETWORK
5
26
H-258
COOLANT PUMP
1
27
H-259
COOLANT NOZZLE
1
28
H-261-8
UP-DOWN CHIP GUARD – SMX 4000
1
H-261-14
UP-DOWN CHIP GUARD - SMX 5000
1
29
H-263-10
BRACKET OF UP-DOWN CHIP GUARD - SMX4000
1
H-263-14
BRACKET OF UP-DOWN CHIP GUARD - SMX5000
1
30
H-264-10
AUTO LUBRICATION PUMP
1
31
H-267-10
TEFLON(L) – SMX 4000
1
H-267-14
TEFLON(L) – SMX 5000
1
32
H-268-10
TEFLON(R) – SMX 4000
1
H-268-14
TEFLON(R) – SMX 5000
1
33
H-279-8
GUARD
1
34
H-280-8
FIXED PLATE(L) – SMX 4000
1
H-280-14
FIXED PLATE(L) – SMX 5000
1
35
H-281-8
FIXED PLATE(R) – SMX 4000
1
H-281-14
FIXED PLATE(R) – SMX 5000
1
36
HT-002-6
HANDWHEEL
1
37
HT-002-6A
CLUTCH
1
38
HT-004
CROSS FEED DIAL
3
39
HT-005-3
DIAL HOLDER
1
40
HT-022-8
FEED NUT BARCKET
1
41
HT-022-8B
FIXED HOLDER OF BALL SCREW
(SMX4000 ONLY)
1
