XYZ Machine Tools SMX 5000 User Manual

91
XYZ Machine Tools Ltd
XYZ Bed Mill Safety, Installation, Maintenance, Service & Parts List Manual
ITEM
P/N
DESCRIPTION
QTY
42
HT-027-8D
BALL SCREW
1
43
HT-028-7A
CROSS FEED BEARING BRACKET
1
44
HT-028-8B
CROSS FEED BEARING BRACKET
1
45
HT-029-8
TABLE
1
46
HT-041-8
BUSHING
1
47
HT-042-8A
BELT PULLEY
1
48
HT-077-7
BEARING BLOCK
1
49
HT-078-7
BEARING COVER
1
50
HT-096-8A
COVER
1
51
HT-142-8
COVER – SMX 4000
1
HT-142-8A
COVER – SMX 5000
1
52
HX-005
LOCKING NUT
2
53
HX-046
STOP BLOCK OF LIMT SWITCH
2
54
HY-065-8
CROSS DUST GUARD – SMX4000
1
HY-065-14
CROSS DUST GUARD – SMX5000
1
55
HY-066-8
FOOT REST
1
56
HY-066-8A
FOOT REST
1
57
HY-073-8
BEARING BRACKET OF BALL SCREW
1
58
HY-083-9
BUSHING
2
59
HANDLE
1
60
MICRO SWITCH
1
61
24428-1
MOTOR (INCLUDES ITEM 62)
1
62
24427
BELT PULLEY
63
670-5M-15
BELT
1
64
AB6204ZZ
BEARING:6204ZZ
2
65
AB2562
BEARING:MM25BS62DH – SMX4000
2
AB2552
BEARING:MM25BS52DH – SMX5000
2
66
AK0303015
KEY:3x3x15
1
67
AK0505020
KEY:5x5x20
2
68
AK0505022
KEY:5x5x22
1
69
AKP138
PIPE:3/8”
2
70
AKP212
PIPE:1/2”
2
71
ANN115025
NUT:M25x1.5
2
72
ANI118516
NUT:5/16”-18NC
6
73
ASM105010
SCREW:M5x0.8x10L
5
74
ASI231638
SCREW:3/16”-24NC-3/8”L
26
75
ASI61458
SCREW:1/4”-20NC-5/8”L
29
76
ASI61434
SCREW:1/4”-20NC-3/4”L
10
77
ASI614158
SCREW:1/4”-20NC-1 5/8”L
2
78
ASI614134
SCREW:1/4”-20NC-1 3/4”L
2
79
ASI651612
SCREW:5/16”-18NC-1/2”L
4
80
ASI651634
SCREW:5/16”-18NC-3/4”L
14
81
ASI65161
SCREW:5/16”-18NC-1”L
6
82
ASI678312
SCREW:7/8”-9NC-3 1/2”L
6
83
AWIH0114
WASHER:1/4”
1
84
AWIH01516
WASHER:5/16”
18
i01300
