8-4
8
Lower unit (F250G)
È U-transom model
No. Part name Q’ty Remarks
1Gasket 2
39
3939
39
2 Check screw 1
3 Dowel 2
4Plate 1
5 Rubber seal 1
6 Bolt 1 M10 × 45 mm
7Grommet 1
8 Lower unit 1
9Spacer 1
10 Propeller 1
11 Cotter pin 1 39
3939
39
12 Propeller nut 1
13 Washer 1
14 Spacer 1
15 Trim tab 1
16 Bolt 1 M10 × 70 mm/X-transom model
17 Bolt 7 M10 × 45 mm/X-transom model
42 N m (4.2 kgf m, 31.0 ft lb)
47 N
m (4.7 kgf m, 34.7 ft lb)
9 N m (0.9 kgf m, 6.6 ft lb)
9 N m (0.9 kgf m, 6.6 ft lb)
47 N m (4.7 kgf m, 34.7 ft lb)
55 N m (5.5 kgf m, 40.6 ft Ib)
9
15
17
18
17
8
10
11
12
14
13
17
16
6
7
3
4
5
3
1
24
23
1
2
19
20
21
22
31
30
29
27
24
25
26
È
28
Lower unit (F200B) / Lower unit (F250G)
