Panel Controls and Terminals
PSR-E413 Owner’s Manual 13
!5 Dial............................................ pages 58, 83
!6 CATEGORY [ ] and [ ]
buttons ..................................... pages 58, 83
!7 [SONG] button ................................. page 39
!8 [STYLE] button ................................ page 33
!9 [MUSIC DATABASE] button ............ page 49
@0 [VOICE] button................................. page 28
@1 Number buttons [0]–[9],
[+] and [-] buttons.................... pages 58, 83
@2 [PORTABLE GRAND] button .......... page 31
@3 REGIST MEMORY
[MEMORY/BANK], [1], [2] buttons .. page 80
@4 VOICE CONTROL
[SPLIT] button ................................. page 30
[DUAL] button.................................. page 29
[HARMONY] button ......................... page 60
[TOUCH] button ............................... page 65
@5 PITCH BEND wheel ......................... page 66
@6 Drum Kit........................................... page 32
The illustrations next to each key indicate the
drum and percussion instruments assigned to the
keys when “Standard Kit 1” is selected.
@7 USB terminal ............................pages 11, 87
@8 SUSTAIN jack................................... page 11
@9 PHONES/OUTPUT jack ................... page 11
#0 DC IN 12V jack................................. page 10
f
r
Rear Panel
@4
!7
!9
@0
@1
@2
@3
!5
!6
@7 @8
@9 #0
!8
Voice Category List
(page 106)
Rear Panel
Music Database List
(page 114)
