FUEL SYSTEM
Fuel Feed Pump Components and Functions
12/05
6LY3 Service Manual
6-29
© 2007 Yanmar Marine International
Fuel Feed Pump Components
Figure 6-37
Figure 6-37
1–Cover
2 – Priming Pump
3–O-Ring
4 – Priming Pump Valve Spring
5 – Priming Pump Valve
6–Piston
7 – Piston Spring
8–O-Ring
9 – Piston Spring Plug
10 – Roller Guide
11–Roller Pin
12–Roller
13 – Retaining Ring
14–Discharge Valve
15 – Discharge Valve Spring
16–O-Ring
17–Plug
18 – Inter-Spindle
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(11)
(12)
(13)
(10)
(17)
(16)
(15)
(14)
(18)
0005700
