ENGINE
Inspecting the Cylinder Block and Components
5-26 6LY3 Service Manual
© 2007 Yanmar Marine International
Cylinder Head Components and Functions
The head contains six cylinder bores and is installed with 26 head bolts. The valve seats are treated with a
special satellite alloy for superior resistance to heat and wear. The areas between the intake / exhaust valves
are cooled with internal circulating water.
Figure 5-14
Figure 5-14
0005596
(3)
(4)(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(18)
(19)
(20)
(21)
(22)
(13)
(14)
(15)
(16)
(17)
(1)
(2)
