Yanmar 6LY3 series Service Manual

ALTERNATOR
Alternator Components and Functions (12V / 80A)
12/05
6LY3 Service Manual
11-7
© 2007 Yanmar Marine International
Figure 11-3
Figure 11-3
1 – Pulley Nut
2 – Pulley
3 – Ball Bearing
4 – Bearing Retainer
5 – Front Cover Assembly
6–Stator
7–Rotor
8 – IC Regulator
9 – Ball Bearing
10 – Rear Cover
11 – Insulating Bushing
12–Bolt
13–Spacer
14 – Through Bolt
8590
170
(1)
(2)
(5)
(3)
(4)
(6) (7)
(12)
(13)
(14)
(8)
(9)
(10)
(11)
0006274
