YASKAWA A1000 Installation Guide

1.1 Model Number and Nameplate Check
YASKAWA ELECTRIC TOEP C710616 50B YASKAWA AC Drive - A1000 6-Phase/12-Pulse Input Installation Guide 11
 6-Phase/12-Pulse 400 V Class Rated Output
<1> Provides method of mounting drive with backside (heatsink) external to enclosure, with NEMA 12 integrity.
<2> Drives with these specifications do not guarantee complete protection for the environmental conditions indicated.
Normal Duty Heavy Duty
No.
Max. Motor Capacity
kW (HP)
Rated Output
Current A
No.
Max. Motor Capacity
kW (HP)
Rated Output
Current A
0058 30 (40) 58 0058 22 (25-30) 45
0072 37 (50) 72 0072 30 (40) 60
0088 45 (60) 88 0088 37 (50-60) 75
0103 55 (75) 103 0103 45 (50-60) 91
0139 75 (100) 139 0139 55 (75) 112
0165 90 (125) 165 0165 75 (100) 150
0208 110 (150) 208 0208 90 (125-150) 180
0250 132 (200) 250 0250 110 (150) 216
0296 160 (250) 296 0296 132 (200) 260
0362 185 (300) 362 0362 160 (250) 304
0414 220 (350) 414 0414 185 (300) 370
0515 250 (400) 515 0515 220 (350) 450
0675 355 (500-550) 675 0675 315 (400-450-500) 605
CIMR - A U 4 T 0675 U A A
Drive
A1000 Series
No.
Enclosure
Type
Design Revision
Order
No.
Region
Code
U USA
Open
Type
A Japan
T Asia
C Europe
D India
B China
No. Voltage Class
No.
Environmental
Specification
K Gas-resistant
A
M
N
S
Standard
Humidity- and
dust-resistant
Oil-resistant
Vibration-resistant
380-480 Vac 4
Customized Specification
6-Phase/12-Pulse Input
<2>
U
<1>
Refer to the tables below

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
