YASKAWA A1000 Installation Guide

14 YASKAWA ELECTRIC TOEP C710616 50B YASKAWA AC Drive - A1000 6-Phase/12-Pulse Input Installation Guide
2.1 Mechanical Installation
2.1 Mechanical Installation
This section outlines specifications and the environment for proper mechanical installation of the drive.
 Installation Environment
Install the drive in an environment matching the specifications below to help prolong the optimum performance life of the
drive.
Table 2.1 Installation Environment
NOTICE: Avoid placing drive peripheral devices, transformers, or other electronics near the drive as the electrical interference created
can lead to erroneous operation. If such devices must be used in close proximity to the drive, take proper steps to shield the drive from
noise.
NOTICE: Damage to Equipment. Drive heatsink air outlet temperature may be over 80°C. Do not install components above the air
outlet that may be damaged by 80°C air temperature.
NOTICE: Prevent foreign matter such as metal shavings and wire clippings from falling into the drive during installation. Failure to
comply could result in damage to the drive. Place a temporary cover over the top of the drive during installation. Remove the temporary
cover before drive start-up, as the cover will reduce ventilation and cause the drive to overheat.
Environment Conditions
Installation Area Indoors
Ambient Temperature
-10°C to +40°C (Flange Type Enclosure)
Drive reliability improves in environments without wide temperature fluctuations.
When using the drive in an enclosure panel, install a cooling fan or air conditioner in the area to ensure that the air
temperature inside the enclosure does not exceed the specified levels.
Do not allow ice to develop on the drive.
Humidity 95% RH or less and free of condensation
Storage Temperature -20°C to +60°C
Surrounding Area
Install the drive in an area free from:
• oil mist and dust
• metal shavings, oil, water, or other foreign materials
• radioactive materials
• combustible materials (e.g., wood)
• harmful gases and liquids
• excessive vibration
• chlorides
• direct sunlight.
Altitude Up to 1000 m without derating, up to 3000 m with output current and voltage derating.
Vibration
10 Hz to 20 Hz at 9.8 m/s
2
20 Hz to 55 Hz at 5.9 m/s
2
(Models CIMR-A4T0058 to 0165) or 2.0 m/s
2
(Models CIMR-A4T0208 to 0675)
Orientation Install the drive vertically to maintain maximum cooling effects.

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
