64 YASKAWA ELECTRIC TOEP C710616 50B YASKAWA AC Drive - A1000 6-Phase/12-Pulse Input Installation Guide
C.1 UL Standards
C.1 UL Standards
UL Standards Compliance
The UL/cUL mark applies to products in the United States and Canada. It indicates that UL has performed product testing
and evaluation, and determined that their stringent standards for product safety have been met. For a product to receive
UL certification, all components inside that product must also receive UL certification.
Figure C.1
Figure C.1 UL/cUL Mark
This drive is tested in accordance with UL standard UL508C and complies with UL requirements. The conditions
described below must be met to maintain compliance when using this drive in combination with other equipment:
Installation Area
Do not install the drive to an area greater than pollution degree 2 (UL standard).
Ambient Temperature
Install the drive in an environment with an ambient temperature of -10°C to 40°C (Flange Type Enclosure).
Factory Recommended Branch Circuit Protection
Yaskawa recommends installing one of the following types of branch circuit protection on a secondary circuit of a 6-
Phase/12-Pulse transformer to maintain standards compliance.
Refer to local codes for proper Branch Circuit Protection on the primary circuit of a 6-Phase/12-Pulse transformer.
The maximum Time Delay fuse is 175% of drive input current rating listed in Table C.1. This covers any Class CC, J or T
class fuse.
A Class L fuse is also approved for this rating at 175% drive input current listed in Table C .1.
Table C.1 Factory Recommended A1000 AC Drive Branch Circuit Protection
Model
CIMR-A
Nominal Output Power
kW (HP)
AC Drive
Input Amps/Phase <1>
Time-Delay Fuse Class J or T
Rating Amps
4T0058
30 (40)
29 40
4T0072 37 (50) 35.5 50
4T0088 45 (60) 43 60
4T0103 55 (75) 52.5 75
4T0139 75 (100) 71 90
4T0165 90 (125) 85 110
4T0208 110 (150) 103.5 150
4T0250
<1> This amp rating is 1/2 rated current because the 3-Phase current is split between 6 input phases for the 6-Phase/12-Pulse A1000 drive. Use this
amp rating to select input wiring size as recommended in Table 3.2.
132 (200) 124 175
4T0296 160 (250) 150 225
4T0362 185 (300) 173 225
4T0414 220 (350) 205 275
4T0515 250 (400) 232.5 350
4T0675 355 (550) 328.5 450
