52 YASKAWA ELECTRIC TOEP C710616 50B YASKAWA AC Drive - A1000 6-Phase/12-Pulse Input Installation Guide
A.1 Power Ratings
A.1 Power Ratings
 6-Phase/12 Pulse Input 400 V Class Drive Models CIMR-A4T0058 to 0208
Table A.1 Power Ratings (CIMR-A4T0058 to 0208)
Item Specification
CIMR-A4T 0058 0072 0088 0103 0139 0165 0208
Maximum Applicable Motor Capacity
kW (HP) <1>
ND Rating
30
(40)
37
(50)
45
(60)
55
(75)
75
(100)
90
(125)
110
(150)
HD Rating
22
(25-30)
30
(40)
37
(50-60)
45
(50-60)
55
(75)
75
(100)
90
(125-150)
Input
<1> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps should be equal to or greater
than the motor current. Select the appropriate capacity drive if operating the motor continuously above motor nameplate current.
<2> Assumes operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring
conditions, and power supply impedance. This input current rating is the 3-Phase total input current rating. For the 6-Phase input current rating
see Table C.1.
<3> Rated motor capacity is calculated with a rated output voltage of 440 V.
<4> Carrier frequency is set to 2 kHz. Current derating is required in order to raise the carrier frequency.
<5> Carrier frequency can be increased to 8 kHz while keeping this current derating. Higher carrier frequency settings require derating.
<6> Carrier frequency can be increased to 5 kHz while keeping this current derating. Higher carrier frequency settings require derating.
Input Current (A) <2>
ND Rating 58 71 86 105 142 170 207
HD Rating 43 58 71 86 105 142 170
Rated Voltage
Rated Frequency
6-Phase/12-Pulse: 380 Vac to 480 Vac 50/60 Hz
Note: 6-Phase isolated supply with each of the output windings phase shifted
by 30 electrical degrees or Hybrid 6-phase topology.
Allowable Voltage Fluctuation -15% to 10%
Allowable Frequency Fluctuation ±5%
Input Power (kVA)
ND Rating 53.0 64.9 78.6 96.0 130 156 189
HD Rating 39.3 53.0 64.9 78.6 96.0 130 155
Output
Rated Output Capacity
(kVA) <3>
ND Rating <4> 44 55 67 78 106 126 159
HD Rating 34 48 57 69 85 114 137 <6>
Rated Output Current
(A)
ND Rating <4> 58 72 88 103 139 165 208
HD Rating 45 <5> 60 <5> 75 <5> 91 <5> 112 <5> 150 <6> 180 <6>
Overload Tolerance
ND Rating: 120% of rated output current for 60 s
HD Rating: 150% of rated output current for 60 s
(Derating may be required for applications that start and stop frequently)
Carrier Frequency User adjustable between 1 kHz and 15 kHz
User adjustable between 1 kHz and
10 kHz
Maximum Output Voltage (V) Three-phase: 380 V to 480 V (proportional to input voltage)
Maximum Output Frequency (Hz) 400 Hz (user-adjustable)

YASKAWA A1000 Specifications

General

Type	AC Drive
Series	A1000
Input Voltage	200-240V, 380-480V
Frequency Range	0-400 Hz
Horsepower Range	0.5 to 1000 HP
Power Range	0.4 to 630 kW
Control Method	V/f Control
Overload Capacity	150% for 60 seconds
Braking	Dynamic Braking
Communication	Modbus
Safety	Safe Torque Off (STO)
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overheat
Operating Temperature	-10 to +50°C
Storage Temperature	-20 to 60°C
Humidity	5 to 95% RH (non-condensing)
Enclosure	IP20
