YASKAWA A1000

2.1 Mechanical Installation
YASKAWA ELECTRIC TOEP C710616 50B YASKAWA AC Drive - A1000 6-Phase/12-Pulse Input Installation Guide 21
 Panel Cut-Out Dimensions
 Flange Type Enclosure
CIMR-A4T0058U
Figure 2.10
Figure 2.10 Panel Cut-Out Dimensions (CIMR-A4T0058U)
CIMR-A4T0072U
Figure 2.11
Figure 2.11 Panel Cut-Out Dimensions (CIMR-A4T0072U)
97.85 (3.85)
97.85 (3.85)
141.6 (5.57) 141.6 (5.57)
19 (0.75)
376 (14.80)
19
(0.75)
88 (3.46)220 (8.66)
25.5 (1.00)
257 (10.12)
25.5 (1.00)
8-M6 Screw Holes
88 (3.46)
10 (0.39)
unit: mm (inch)
unit: mm (inch)
96.5 (3.80)250 (9.84)
18.5 (0.73)
423 (16.65)
18.5
(0.73)
24.5
(0.96)
281 (11.06)
24.5
(0.96)
8-M6 Screw Holes
103 (4.06) 103 (4.06)
153.8 (6.06) 153.8 (6.06)
96.5 (3.80)
10 (0.39)
