A.1 Power Ratings
YASKAWA ELECTRIC TOEP C710616 50B YASKAWA AC Drive - A1000 6-Phase/12-Pulse Input Installation Guide 53
6-Phase/12 Pulse Input 400 V Class Drive Models CIMR-A4T0208 to 0675
Table A.2 Power Ratings (CIMR-A4T0208 to 0675)
Item Specification
CIMR-A4T 0250 0296 0362 0414 0515 0675
Maximum Applicable
Motor Capacity kW (HP) <1>
ND Rating
132
(200)
160
(250)
185
(300)
220
(350)
250
(400)
355
(500-550)
HD Rating
110
(150)
132
(200)
160
(250)
185
(300)
220
(350)
315
(400-450-500)
Input
<1> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps should be equal to or greater
than the motor current. Select the appropriate capacity drive if operating the motor continuously above motor nameplate current.
<2> Assumes operation at the rated output current. Input current rating varies depending on the power supply transformer, input reactor, wiring
conditions, and power supply impedance. This input current rating is the 3-Phase total input current rating. For the 6-Phase input current rating
see Table C.1.
<3> Rated motor capacity is calculated with a rated output voltage of 440 V.
<4> Carrier frequency is set to 2 kHz. Current derating is required in order to raise the carrier frequency.
<5> Carrier frequency can be increased to 5 kHz while keeping this current derating. Higher carrier frequency settings require derating.
Input Current (A) <2>
ND Rating 228 275 317 376 427 603
HD Rating 190 228 275 317 376 511
Rated Voltage
Rated Frequency
6-Phase/12-Pulse: 380 Vac to 480 Vac 50/60 Hz
Note: 6-Phase isolated supply with each of the output windings phase shifted
by 30 electrical degrees or Hybrid 6-Phase topology.
Allowable Voltage Fluctuation -15% to 10%
Allowable Frequency Fluctuation ±5%
Input Power (kVA)
ND Rating 227 274 316 375 425 601
HD Rating 189 227 274 316 375 534
Output
Rated Output Capacity
(kVA) <3>
ND Rating <4> 191 226 276 316 392 514
HD Rating 165 <5> 198 <5> 232 <5> 282 <4> 343 <4> 461 <4>
Rated Output Current
(A)
ND Rating <4> 250 296 362 414 515 675
HD Rating 216 <5> 260 <5> 304 <5> 370 <4> 450 <4> 605 <4>
Overload Tolerance
ND Rating: 120% of rated output current for 60 s
HD Rating: 150% of rated output current for 60 s
(Derating may be required for applications that start and stop frequently)
Carrier Frequency User-adjustable between 1 kHz and 10 kHz User-adjustable between 1 kHz and 5 kHz
Maximum Output Voltage (V) Three-phase: 380 V to 480 V (proportional to input voltage)
Maximum Output Frequency (Hz) 400 Hz (user-adjustable)
