A.3 Drive Watt Loss Data
A.3 Drive Watt Loss Data
Table A.3 Watt Loss
Model
CIMR-A
<1> Value assumes the carrier frequency is set to 2 kHz.
<2> Value assumes the carrier frequency is set to 5 kHz or less.
<3> Value assumes the carrier frequency is set to 8 kHz or less.
Normal Duty Heavy Duty
Rated Amps
(A) <1>
Heatsink
Loss
(W)
Interior Unit
Loss (W)
Total Loss
(W)
Rated Amps
(A)
Heatsink
Loss
(W)
Interior Unit
Loss (W)
Total Loss
(W)
4T0058 58 453 197 651 45 <3> 341 159 501
4T0072 72 588 244 835 60 <3> 477 206 685
4T0088 88 669 285 957 75 <3> 556 241 800
4T0103 103 827 329 1160 91 <3> 714 285 1001
4T0139 139 1179 487 1672 112 <3> 1100 447 1562
4T0165 165 1520 624 2148 150 <3> 1647 629 2293
4T0208 208 1746 553 2299 180 <3> 2199 586 2786
4T0250 250 2305 729 3034 216 <2> 2308 663 2971
4T0296 296 2308 772 3077 260 <2> 2295 694 2987
4T0362 362 3168 874 4016 304 <2> 3075 788 3846
4T0414 414 3443 1083 4524 370 <2> 3578 1012 4590
4T0515 515 4850 1474 6323 450 <1> 3972 1234 5206
4T0675 675 4861 1789 6648 605 <1> 4191 1504 5695
