Startup Procedure and Test Run
4
4.4 Drive Mode and Programming Mode
YASKAWA SIEPC71061753C GA500 Technical Manual 129
Figure 4.8 Key operation examples in Setup Mode
◆ Change Parameter Settings
Show the frequency reference screen in advance.
Note:
Push and hold to go back to the frequency reference screen from any screen.
Use these steps to change C1-01 [Acceleration Time 1] from 1.0 s (default) to 2.0 s.
Figure 4.9 Key Operation Examples for Parameter Settings
◆ Verify and Set the Changed Parameters (Verify Menu)
Show the frequency reference screen.
Note:
Push and hold to return to frequency reference screen from any screen.
Use Verify mode to view all parameters that are not at default settings. This is very useful when you replace a
drive. When there are no changes to parameter settings, the display shows . This lets you quickly access
and re-edit changed parameters. Figure 4.10 shows the procedure.
Figure 4.10 Verify and Set the Changed Parameters
