11.20 Parameters Changed by E1-03 [V/f Pattern Selection]
YASKAWA SIEPC71061753C GA500 Technical Manual 465
11.20 Parameters Changed by E1-03 [V/f Pattern Selection]
The values for parameters A1-02 [Control Method Selection] and E1-03 [V/f Pattern Selection] change the default
settings for the parameters in these tables:
Table 11.3 Parameters Changed by E1-03 (B001 - B018, 2001 - 2021, and 4001 - 4012)
No.
Unit
Setting Value
Control Method (A1-
02 Setting)
E1-03 0 1 2 3 4 5 6 7 8 9 A B C D E
F
*1
OLV
(2)
OLV/
PM
(5)
AOL
V/PM
(6)
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 50.0 50.0
*2 *2
E1-05
*3
V 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0
*2 *2
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 50.0 50.0
*2 *2
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 2.5 3.0 - -
E1-08
*3
V 16.0 16.0 16.0 16.0 35.0 50.0 35.0 50.0 19.0 24.0 19.0 24.0 16.0 16.0 16.0 16.0 14.4 - -
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.3 0.5
*2 *2
E1-10
*3
V 12.0 12.0 12.0 12.0 8.0 9.0 8.0 9.0 12.0 13.0 12.0 15.0 12.0 12.0 12.0 12.0 3.0 - -
*1 These values are the default settings for E1-04 to E1-10 and E3-04 to E3-10 [V/f Pattern for Motor 2]. These settings are the same as
those for the V/f pattern when E1-03 = 0 [Const Trq, 50 Hz base, 60Hz max].
*2 The default setting varies depending on the setting of E5-01 [PM Motor Code Selection].
*3 This is the value for 200 V class drives. Double the value for 400 V class drives.
Table 11.4 Parameters Changed by E1-03 (2030 - 2082 and 4018 - 4060)
No.
Unit
Setting Value
Control Method (A1-
02 Setting)
E1-03 0 1 2 3 4 5 6 7 8 9 A B C D E
F
*1
OLV
(2)
OLV/
PM
(5)
AOL
V/PM
(6)
E1-04 Hz 50.0 60.0 60.0 72.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 90.0 120.0 180.0 50.0 50.0
*2 *2
E1-05
*3
V 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0 200.0
*2 *2
E1-06 Hz 50.0 60.0 50.0 60.0 50.0 50.0 60.0 60.0 50.0 50.0 60.0 60.0 60.0 60.0 60.0 50.0 50.0
*2 *2
E1-07 Hz 2.5 3.0 3.0 3.0 25.0 25.0 30.0 30.0 2.5 2.5 3.0 3.0 3.0 3.0 3.0 2.5 3.0 - -
E1-08
*3
V 14.0 14.0 14.0 14.0 35.0 50.0 35.0 50.0 18.0 23.0 18.0 23.0 14.0 14.0 14.0 14.0 13.2 - -
E1-09 Hz 1.3 1.5 1.5 1.5 1.3 1.3 1.5 1.5 1.3 1.3 1.5 1.5 1.5 1.5 1.5 1.3 0.5
*2 *2
E1-10
*3
V 7.0 7.0 7.0 7.0 6.0 7.0 6.0 7.0 9.0 11.0 9.0 13.0 7.0 7.0 7.0 7.0 2.4 - -
*1 These values are the default settings for E1-04 to E1-10 and E3-04 to E3-10 [V/f Pattern for Motor 2]. These settings are the same as
those for the V/f pattern when E1-03 = 0 [Const Trq, 50 Hz base, 60Hz max].
*2 The default setting varies depending on the setting of E5-01 [PM Motor Code Selection].
*3 This is the value for 200 V class drives. Double the value for 400 V class drives.
