YASKAWA CIPR-GA50CB001

Parameter Details
12
12.8 H: Terminal Function Selection
YASKAWA SIEPC71061753C GA500 Technical Manual 625
12.8 H: Terminal Function Selection
H parameters set functions for external input and output terminals.
◆ H1: Digital Inputs
H1 Parameters set the MFDI terminal functions.
■ H1-01 to H1-07 Terminal S1 to S7 Function Selection
The drive has 7 MFDI terminals. Refer to Table 12.53 for drive default settings and functions.
Table 12.53 MFDI Default Settings and Functions
No. Name Default Function
H1-01 Terminal S1 Function Selection 40 (F)
*1
Forward RUN (2-Wire)
H1-02 Terminal S2 Function Selection 41 (F)
*1
Reverse RUN (2-Wire)
H1-03 Terminal S3 Function Selection 24 External Fault (NO-Always-Coast)
H1-04 Terminal S4 Function Selection 14 Fault Reset
H1-05 Terminal S5 Function Selection 3 (0)
*1
Multi-Step Speed Reference 1
H1-06 Terminal S6 Function Selection 4 (3)
*1
Multi-Step Speed Reference 2
H1-07 Terminal S7 Function Selection 6 (4)
*1
Jog Reference Selection
*1 The value in parentheses identifies the default setting when you set A1-03 = 3330 [Initialize Parameters = 3-Wire Initialization].
Refer to the and use H1-xx [MFDI Function Select] to set the function.
Refer to the Table 12.54 and use H1-xx [MFDI Function Select] to set the function.
Table 12.54 MFDI Setting Values
Setting Value Function Ref.
0
*1
3-Wire Sequence
628
1 LOCAL/REMOTE Selection
629
2 External Reference 1/2 Selection
630
3 Multi-Step Speed Reference 1
630
4 Multi-Step Speed Reference 2
630
5 Multi-Step Speed Reference 3
630
6 Jog Reference Selection
630
7 Accel/Decel Time Selection 1
630
8
*1
Baseblock Command (N.O.)
630
9
*1
Baseblock Command (N.C.)
631
A Accel/Decel Ramp Hold
631
B Overheat Alarm (oH2)
631
C Analog Terminal Enable Selection
631
E ASR Integral Reset
632
F Through Mode
632
10 Up Command
632
11 Down Command
633
12
*1
Forward Jog
634
13
*1
Reverse Jog
634
14 Fault Reset
634
15
*1
Fast Stop (N.O.)
635
16 Motor 2 Selection
635
17
*1
Fast Stop (N.C.)
636
18 Timer Function
636
19 PID Disable
636
Setting Value Function Ref.
1A Accel/Decel Time Selection 2
636
1B
*2
Programming Lockout
636
1E Reference Sample Hold
637
20 to 2F
*1
External Fault
637
30 PID Integrator Reset
638
31 PID Integrator Hold
638
32 Multi-Step Speed Reference 4
638
34 PID Soft Starter Disable
638
35 PID Input (Error) Invert
639
3E PID Setpoint Selection 1
639
3F PID Setpoint Selection 2
639
40
*1
Forward RUN (2-Wire)
639
41
*1
Reverse RUN (2-Wire)
639
42
*1
Run Command (2-Wire Sequence 2)
640
43
*1
FWD/REV (2-Wire Sequence 2)
640
44 Add Offset Frequency 1 (d7-03)
640
45 Add Offset Frequency 2 (d7-03)
640
46 Add Offset Frequency 3 (d7-03)
640
47 Node Setup (CANopen)
640
60 DC Injection Braking Command
641
61 Speed Search from Fmax
641
62 Speed Search from Fref
641
63 Field Weakening
641
65
*1
KEB Ride-Thru 1 Activate (N.C.)
641
66
*1
KEB Ride-Thru 1 Activate (N.O.)
642
