12.8 H: Terminal Function Selection
640 YASKAWA SIEPC71061753C GA500 Technical Manual
Note:
• If you turn ON the Forward Run command terminal and the Reverse Run command terminal, it will cause an EF [FWD/REV Run
Command Input Error] alarm and the motor will ramp to stop.
• Initialize the drive with a 2-wire sequence to set the Reverse Run command to terminal S2.
• This function will not operate at the same time as H1-xx = 42, 43 [Run Command (2-Wire Sequence 2), FWD/REV (2-Wire Sequence
2)].
■ 42: Run Command (2-Wire Sequence 2)
Setting Value Function Description
42 Run Command (2-Wire
Sequence 2)
Sets the Run command for 2-wire sequence 2. Set this function and H1-xx = 43 [FWD/REV (2-Wire Sequence 2)] together.
ON : Run
OFF : Stop
Note:
This function will not operate at the same time as H1-xx = 40, 41 [Forward RUN (2-Wire), Reverse RUN (2-Wire)].
■ 43: FWD/REV (2-Wire Sequence 2)
Setting Value Function Description
43 FWD/REV (2-Wire
Sequence 2)
Sets the direction of motor rotation for 2-wire sequence 2. Set this function and H1-xx = 42 [Run Command (2-Wire Sequence
2)] together.
ON : Reverse Run
OFF : Forward Run
Note:
• You must input the Run command to rotate the motor.
• This function will not operate at the same time as H1-xx = 40, 41 [Forward RUN (2-Wire), Reverse RUN (2-Wire)].
■ 44: Add Offset Frequency 1 (d7-01)
Setting Value Function Description
44 Add Offset Frequency 1
(d7-01)
Sets the function to add the offset frequency set in d7-01 [Offset Frequency 1] to the frequency reference when the terminal
activates.
Note:
Refer to d7: Offset Frequency on page 580 for more information.
■ 45: Add Offset Frequency 2 (d7-02)
Setting Value Function Description
45 Add Offset Frequency 2
(d7-02)
Sets the function to add the offset frequency set in d7-02 [Offset Frequency 2] to the frequency reference when the terminal
activates.
Note:
Refer to d7: Offset Frequency on page 580 for more information.
■ 46: Add Offset Frequency 3 (d7-03)
Setting Value Function Description
46 Add Offset Frequency 3
(d7-03)
Sets the function to add the offset frequency set in d7-03 [Offset Frequency 3] to the frequency reference when the terminal
activates.
Note:
Refer to d7: Offset Frequency on page 580 for more information.
■ 47: Node Setup (CANopen)
Setting Value Function Description
47 Node Setup (CANopen)
Sets the function in CANopen communications to start the Node Setup function to set the drive node address from the host
controller.
