Parameter List
11
11.9 F: Options
YASKAWA SIEPC71061753C GA500 Technical Manual 385
11.9 F: Options
◆ F1: Fault Detection in PG Speed Control
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F1-02
(0381)
Encoder Signal Loss
Detect Sel
Sets the method to stop the motor or let the motor continue operating when the drive
detects PGo [Encoder (PG) Feedback Loss].
0 : Ramp to Stop
1 : Coast to Stop
2 : Fast Stop (Use C1-09)
3 : Alarm Only
4 : No Alarm Display
Note:
When A1-02 = 0 [Control Method Selection = V/f], set H6-01 = 3 [Terminal RP
Pulse Train Function = Speed Feedback (V/F Control)] to enable this parameter.
1
(0 - 4)
602
F1-03
(0382)
Overspeed Detection
Selection
Sets the method to stop the motor or let the motor continue to operate when the drive
detects oS [Overspeed].
0 : Ramp to Stop
1 : Coast to Stop
2 : Fast Stop (Use C1-09)
3 : Alarm Only
Note:
When A1-02 = 0 [Control Method Selection = V/f], set H6-01 = 3 [Terminal RP
Pulse Train Function = Speed Feedback (V/F Control)] to enable this parameter.
1
(0 - 3)
602
F1-04
(0383)
Speed Deviation
Detection Select
Sets the method to stop the motor or let the motor continue to operate when the drive
detects dEv [Speed Deviation].
0 : Ramp to Stop
1 : Coast to Stop
2 : Fast Stop (Use C1-09)
3 : Alarm Only
Note:
When A1-02 = 0 [Control Method Selection = V/f], set H6-01 = 3 [Terminal RP
Pulse Train Function = Speed Feedback (V/F Control)] to enable this parameter.
3
(0 - 3)
603
F1-08
(0387)
Overspeed Detection
Level
Sets the detection level of oS [Overspeed] as a percentage when the maximum output
frequency is 100%.
Note:
• Parameter A1-02 [Control Method Selection] selects which parameter is the
maximum output frequency.
–A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
–A1-02 = 8: E9-02 [Motor Max Revolutions]
• When A1-02 = 0 [Control Method Selection = V/f], set H6-01 = 3 [Terminal RP
Pulse Train Function = Speed Feedback (V/F Control)] to enable this parameter.
115%
(0 - 120%)
603
F1-09
(0388)
Overspeed Detection
Delay Time
Sets the length of time that the speed feedback must be more than the F1-08 level to
cause oS [Overspeed].
Note:
When A1-02 = 0 [Control Method Selection = V/f], set H6-01 = 3 [Terminal RP
Pulse Train Function = Speed Feedback (V/F Control)] to enable this parameter.
Determined by A1-02
(0.0 - 2.0 s)
604
F1-10
(0389)
Speed Deviation
Detection Level
Sets the detection level of dEv [Speed Deviation] as a percentage when the maximum
output frequency is 100%.
Note:
• Parameter A1-02 [Control Method Selection] selects which parameter is the
maximum output frequency.
–A1-02 ≠ 8 [EZOLV]: E1-04 [Maximum Output Frequency]
–A1-02 = 8: E9-02 [Maximum Speed]
• When A1-02 = 0 [Control Method Selection = V/f], set H6-01 = 3 [Terminal RP
Pulse Train Function = Speed Feedback (V/F Control)] to enable this parameter.
10%
(0 - 50%)
604
