11.13 o: Keypad-Related Settings
YASKAWA SIEPC71061753C GA500 Technical Manual 435
11.13 o: Keypad-Related Settings
◆ o1: Keypad Display
No.
(Hex.)
Name Description
Default
(Range)
Ref.
o1-01
(0500)
RUN
User Monitor Selection
Sets the U monitor for the Drive Mode. This parameter is only available with an LED
keypad.
106
(104 - 855)
758
o1-02
(0501)
RUN
Monitor Selection at
Power-up
Sets the monitor item that the keypad screen shows after you energize the drive. Refer
to “U: Monitors” for information about the monitor items that the keypad screen can
show. This parameter is only available with an LED keypad.
1 : Frequency Reference (U1-01)
2 : Direction
3 : Output Frequency (U1-02)
4 : Output Current (U1-03)
5 : User Monitor (o1-01)
1
(1 - 5)
758
o1-03
(0502)
Frequency Display Unit
Selection
Sets the display units for the frequency reference and output frequency.
0 : 0.01 Hz
1 : 0.01% (100% = E1-04)
2 : Revolutions Per Minute (RPM)
3 : User units (Set with o1-10, o1-11)
Determined by A1-02
(0 - 3)
758
o1-04
(0503)
V/f Pattern Display Unit
Sets the setting unit for parameters that set the V/f pattern frequency.
0 : Hz
1 : min
-1
(r/min) units
Determined by A1-02
(0, 1)
759
o1-05
(0504)
RUN
LCD Contrast
Adjustment
Sets the contrast of the LCD display on the keypad.
5
(0 - 10)
759
o1-10
(0520)
User Units Maximum
Value
Sets the value that the drive shows as the maximum output frequency.
Determined by o1-03
(1 - 60000)
759
o1-11
(0521)
User Units Decimal
Position
Sets the number of decimal places for frequency reference and monitor values.
0 : No Decimal Places (XXXXX)
1 : One Decimal Places (XXXX.X)
2 : Two Decimal Places (XXX.XX)
3 : Three Decimal Places (XX.XXX)
Determined by o1-03
(0 - 3)
760
o1-24
(11AD)
RUN
Custom Monitor 1
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the first line. The
registered monitor is also used for different monitor displays of bar graph, analog meter,
and waveform.
101
(0, 101 - 999)
760
o1-25
(11AE)
RUN
Custom Monitor 2
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the second line. The
registered monitor is also used for different monitor displays of bar graph and
waveform.
102
(0, 101 - 999)
760
o1-26
(11AF)
RUN
Custom Monitor 3
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the third line. The
registered monitor is also used for the monitor display of the bar graph.
103
(0, 101 - 999)
760
o1-27
(11B0)
RUN
Custom Monitor 4
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the fourth line.
0
(0, 101 - 999)
760
o1-28
(11B1)
RUN
Custom Monitor 5
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the fifth line.
0
(0, 101 - 999)
760
o1-29
(11B2)
RUN
Custom Monitor 6
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the sixth line.
0
(0, 101 - 999)
760
o1-30
(11B3)
RUN
Custom Monitor 7
You can select a maximum of 12 monitors as user monitors and set them to parameters
o1-24 to o1-35. This parameter sets the user monitor to show on the seventh line.
0
(0, 101 - 999)
760
