Standards Compliance
5
5.2 European Standards
YASKAWA SIEPC71061753C GA500 Technical Manual 183
A - SW (ON) B - SW (OFF)
Figure 5.8 EMC Filter Switch Location 1
A - SW (ON) B - SW (OFF)
Figure 5.9 EMC Filter Switch Location 2
A - SW (ON) B - SW (OFF)
Figure 5.10 EMC Filter Switch Location 3
If you lose an EMC filter switch screw, use Table 5.11 to find the correct replacement screw and install the new
screw with the correct tightening torque.
NOTICE: Only use the screws specified in this manual. If you use screws that are not approved, it can cause damage to the
drive.
