5.3 UL Standards
YASKAWA SIEPC71061753C GA500 Technical Manual 193
Model Terminal
Recomm. Gauge
AWG, kcmil
Applicable Gauge
AWG, kcmil
Wire Stripping
Length
*1
mm
Terminal Screw
Size and Shape
Tightening Torque
N∙m (lbf∙in)
2021
R/L1, S/L2, T/L3 8 14 - 8 10
M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 10 14 - 8 10
M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 8 14 - 8 10
M4
1.5 - 1.7
(13.5 - 15)
B1, B2 14 14 - 10 10
M4
1.5 - 1.7
(13.5 - 15)
8
*2
14 - 8
*2
-
M4
1.2 - 1.5
(10.6 - 13.3)
2030
R/L1, S/L2, T/L3 8 12 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 8 12 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 6 12 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
B1, B2 12 12 - 8 10
M4
1.5 - 1.7
(13.5 - 15)
8 10 - 6 -
M5
2.0 - 2.5
(17.7 - 22.1)
2042
R/L1, S/L2, T/L3 6 12 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
U/T1, V/T2, W/T3 6 12 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
-, +1, +2 4 10 - 2 18
M5
• ≤ AWG 10
2.3 - 2.5
(19.8 - 22)
• AWG 8 ≤
4.1 - 4.5
(36 - 40)
B1, B2 10 14 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
6 10 - 6 -
M5
2.0 - 2.5
(17.7 - 22.1)
2056
R/L1, S/L2, T/L3 4 10 - 2 18
M5
4.1 - 4.5
(36 - 40)
U/T1, V/T2, W/T3 4 10 - 2 18
M5
• ≤ AWG 10
2.3 - 2.5
(19.8 - 22)
• AWG 8 ≤
4.1 - 4.5
(36 - 40)
-, +1, +2 2 8 - 2 18
M5
4.1 - 4.5
(36 - 40)
B1, B2 8 12 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
6 8 - 4 -
M6
5.4 - 6.0
(47.8 - 53.1)
2070
R/L1, S/L2, T/L3 2 6 - 1 20
M6
5 - 5.5
(45 - 49)
U/T1, V/T2, W/T3 2 8 - 1 20
M6
5 - 5.5
(45 - 49)
-, +1, +2 1 6 - 1/0 20
M6
5 - 5.5
(45 - 49)
B1, B2 8 12 - 6 10
M4
1.5 - 1.7
(13.5 - 15)
4 6 - 4 -
M6
5.4 - 6.0
(47.8 - 53.1)
