6.3 MEMOBUS/Modbus Communications
236 YASKAWA SIEPC71061753C GA500 Technical Manual
Register No.
(Hex.)
Description
00AB
Drive rated current
Note:
The unit of display is different for different models.
B001 - B018, 2001 - 2042, and 4001 - 4023: 0.01 A
2056 - 2082, 4031 - 4060: 0.1 A
00AC
U1-05 [Motor Speed]
Units: min
-1
or r/min
Note:
Set E2-04, E4-04, E5-04, E9-08 [Motor Pole Count].
00AD
Units: 0.01%
00AE, 00AF Reserved
00B0
Option codes connected to
CN5
The drive stores option codes in the register.
SI-C3 = 5343 (Hex.)
SI-EM3 = 1005 (Hex.)
SI-EN3 = 1006 (Hex.)
SI-EP3 = 1007 (Hex.)
SI-ES3 = 1001 (Hex.)
SI-ET3 = 1004 (Hex.)
SI-N3 = 534E (Hex.)
SI-P3 = 5350 (Hex.)
SI-S3 = 5353 (Hex.)
SI-T3 = 5354 (Hex.)
00B1 - 00B4 Reserved
00B5
U1-16 [SFS Output
Frequency]
Units: min
-1
or r/min
Note:
Set E2-04, E4-04, E5-04, E9-08 [Motor Pole Count].
00B6
Units: 0.01%
00B7
Frequency reference
monitor
Units: min
-1
or r/min
Note:
Set E2-04, E4-04, E5-04, E9-08 [Motor Pole Count].
00B8
Units: 0.01%
00B9 - 00BE Reserved
00BF
Operation error number
xx of oPExx is displayed.
00C0
Fault Description 3
bit 0 Reserved
bit 1 Uv1 [DC Bus Undervoltage]
bit 2 Uv2 [Control Power Undervoltage]
bit 3 Uv3 [Soft Charge Answerback Fault]
bit 4 SC [Short Circuit/IGBT Failure]
bit 5 GF [Ground Fault]
bit 6 oC [Overcurrent]
bit 7 ov [Overvoltage]
bit 8 oH [Heatsink Overheat]
bit 9 oH1 [Heatsink Overheat]
bit A oL1 [Motor Overload]
bit B oL2 [Drive Overload]
bit C oL3 [Overtorque Detection 1]
bit D oL4 [Overtorque Detection 2]
bit E rr [Dynamic Braking Transistor Fault]
bit F rH [Braking Resistor Overheat]
