YASKAWA CIPR-GA50CB001 Technical Manual

Specifications
10
10.7 Drive Derating
YASKAWA SIEPC71061753C GA500 Technical Manual 341
Model
Rated Current (A)
Heavy Duty Rating (HD)
[C6-01 = 0]
Normal Duty Rating (ND)
[C6-01 = 1]
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
2021
17.6 17.6 17.6 16.6 15.3 14.1 21.0 19.8 18.1 17.0 15.5 14.1
2030 25.0 25.0 25.0 23.6 21.8 20 30.0 28.3 25.8 24.2 22.1 20
2042 33.0 33.0 33.0 31.1 28.8 26 42.0 39.4 35.5 32.9 29.7 26
2056 47.0 47.0 47.0 44.3 41.0 38 56.0 52.9 48.3 45.3 41.4 38
2070 60.0 60.0 60.0 56.6 52.3 48 70.0 66.3 60.8 57.2 52.6 48
2082 75.0 75.0 75.0 70.7 65.4 60 82.0 81.4 75.0 70.7 65.4 60
Table 10.16 AOLV/PM Carrier Frequency and Rated Current Derating (Three-Phase 200 V)
Model
Rated Current (A)
Heavy Duty Rating (HD)
[C6-01 = 0]
Normal Duty Rating (ND)
[C6-01 = 1]
2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz 2 kHz 4 kHz 6 kHz 8 kHz 10 kHz 12 kHz
2001
0.8 0.8 0.8 0.7 0.6 0.5 1.2 1.1 0.9 0.8 0.6 0.5
2002
1.6 1.6 1.6 1.5 1.3 1.1 1.9 1.9 1.7 1.5 1.3 1.1
2004
3.0 3.0 3.0 2.8 2.4 2.0 3.5 3.5 3.1 2.8 2.4 2.0
2006
5.0 5.0 5.0 4.6 4.0 3.4 6.0 5.8 5.2 4.6 4.0 3.4
2008
6.9 6.9 6.7 6.1 5.5 4.9 8.0 7.4 6.8 6.1 5.5 4.9
2010
8.0 8.0 7.8 7.1 6.4 5.7 9.6 8.8 8.0 7.2 6.4 5.6
2012
11.0 11.0 10.7 9.7 8.8 7.9 12.2 11.6 10.7 9.7 8.8 7.9
2018
14.0 14.0 13.6 12.4 11.2 10.0 17.5 15.9 14.4 12.8 11.2 9.6
2021
17.6 17.6 17.1 15.6 14.1 12.6 21.0 19.3 17.5 15.8 14.1 12.4
2030
25.0 25.0 24.3 22.1 20.0 17.9 30.0 27.5 25.0 22.5 20.0 17.5
2042
33.0 33.0 32.1 29.2 26.4 23.6 42.0 38.1 34.2 30.3 26.4 22.5
2056
47.0 47.0 45.7 41.6 37.6 33.6 56.0 51.4 46.8 42.2 37.6 33.0
2070
60.0 60.0 58.3 53.1 48.0 42.9 70.0 64.5 59.0 53.5 48.0 42.5
2082
75.0 75.0 72.9 66.4 60.0 53.6 82.0 79.3 72.9 66.4 60.0 53.6
■ Three-Phase 400 V Class
Table 10.17 Carrier Frequency and Rated Current Derating (Three-Phase 400 V)
Model
Rated Current (A)
Heavy Duty Rating (HD)
[C6-01 = 0]
Normal Duty Rating (ND)
[C6-01 = 1]
2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz 2 kHz 5 kHz 8 kHz 10 kHz 12.5 kHz 15 kHz
4001 1.2 1.2 1.2 1.1 0.9 0.7 1.2 1.2 1.2 1.1 0.9 0.7
4002 1.8 1.8 1.8 1.6 1.3 1.1 2.1 2.1 1.8 1.6 1.3 1.1
4004 3.4 3.4 3.4 3.0 2.5 2.0 4.1 4.0 3.4 3.0 2.5 2.0
4005 4.8 4.8 4.8 4.3 3.6 2.9 5.4 5.4 4.8 4.2 3.6 2.9
4007 5.5 5.5 5.5 4.9 4.1 3.3 7.1 6.5 5.5 4.9 4.1 3.3
4009 7.3 7.3 7.3 6.5 5.4 4.4 8.9 8.6 7.3 6.5 5.4 4.4
4012 9.2 9.2 9.2 8.1 6.8 5.5 11.9 10.8 9.2 8.2 6.8 5.5
4018 14.8 14.8 14.8 13.1 11.0 8.9 17.5 17.0 14.5 12.8 10.8 8.7
4023 18.0 18.0 18.0 15.9 13.4 10.8 23.4 21.3 18.2 16.1 13.4 10.8
4031 24.0 24.0 24.0 21.3 17.8 14.4 31.0 28.2 24.1 21.3 17.9 14.4
4038 31.0 31.0 31.0 27.5 23.0 18.6 38.0 36.3 31.0 27.5 23.0 18.6
