YASKAWA CIPR-GA50CB001 Technical Manual

Specifications
10
10.8 Drive Exterior and Mounting Dimensions
YASKAWA SIEPC71061753C GA500 Technical Manual 345
Table 10.23 Single-Phase 200 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1
d
B001E
68
(2.68)
128
(5.04)
116
(4.57)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
6.5
(0.26)
3
(0.12)
M5
0.7
(1.6)
B002E
68
(2.68)
128
(5.04)
116
(4.57)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
6.5
(0.26)
3
(0.12)
M5
0.7
(1.6)
B004E
68
(2.68)
128
(5.04)
158
(6.22)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
38.5
(1.52)
5
(0.20)
M5
1.0
(2.2)
Table 10.24 Three-Phase 200 V Class (IP20/UL Open Type, without Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1
d
2001A
68
(2.68)
128
(5.04)
76
(2.99)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
6.5
(0.26)
3
(0.12)
M5
0.5
(1.1)
2002A
68
(2.68)
128
(5.04)
76
(2.99)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
6.5
(0.26)
3
(0.12)
M5
0.5
(1.1)
2004A
68
(2.68)
128
(5.04)
108
(4.25)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
38.5
(1.52)
5
(0.20)
M5
0.8
(1.8)
2006A
68
(2.68)
128
(5.04)
128
(5.04)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
58.5
(2.30)
5
(0.20)
M5
0.9
(2.0)
Table 10.25 Three-Phase 200 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1
d
2001E
68
(2.68)
128
(5.04)
116
(4.57)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
6.5
(0.26)
3
(0.12)
M5
0.6
(1.3)
2002E
68
(2.68)
128
(5.04)
116
(4.57)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
6.5
(0.26)
3
(0.12)
M5
0.6
(1.3)
2004E
68
(2.68)
128
(5.04)
148
(5.83)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
38.5
(1.52)
5
(0.20)
M5
0.9
(2.0)
2006E
68
(2.68)
128
(5.04)
168
(6.61)
56
(2.20)
6
(0.24)
118
(4.65)
5
(0.20)
58.5
(2.30)
5
(0.20)
M5
1.1
(2.4)
■ B006 - B018, 2008 - 2021, 4001 - 4012
Figure 10.3 Dimension Diagram 1
