10.8 Drive Exterior and Mounting Dimensions
348 YASKAWA SIEPC71061753C GA500 Technical Manual
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
2056A
180
(7.09)
300
(11.81)
143
(5.63)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
5.5
(12.1)
2070A
220
(8.66)
350
(13.78)
187
(7.36)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
7.5
(16.5)
2082A
220
(8.66)
350
(13.78)
187
(7.36)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
8.0
(17.6)
Table 10.33 Three-Phase 200 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
2030E
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.9
(8.6)
2042E
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
4.1
(9.0)
2056E
180
(7.09)
300
(11.81)
196
(7.72)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
6.0
(13.2)
2070E
220
(8.66)
350
(13.78)
216
(8.50)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
8.5
(18.7)
2082E
220
(8.66)
350
(13.78)
216
(8.50)
192
(7.56)
14
(0.55)
336
(13.23)
7
(0.28)
78
(3.07)
5
(0.20)
M6
9.0
(19.9)
Table 10.34 Three-Phase 400 V Class (IP20/UL Open Type, without Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
4018A
140
(5.51)
260
(10.24)
140
(5.51)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.0
(6.6)
4023A
140
(5.51)
260
(10.24)
140
(5.51)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.2
(7.1)
4031A
180
(7.09)
300
(11.81)
143
(5.63)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
4.6
(10.2)
4038A
180
(7.09)
300
(11.81)
143
(5.63)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
4.8
(10.6)
4044A
190
(7.48)
350
(13.78)
204
(8.03)
160
(6.30)
15
(0.59)
336
(13.23)
7
(0.28)
94
(3.70)
5
(0.20)
M6
6.5
(14.3)
4060A
190
(7.48)
350
(13.78)
204
(8.03)
160
(6.30)
15
(0.59)
336
(13.23)
7
(0.28)
94
(3.70)
5
(0.20)
M6
6.5
(14.3)
Table 10.35 Three-Phase 400 V Class (IP20/UL Open Type, with Built-in EMC Filter)
Model
Dimensions mm (in)
Est.
Weight
kg (lb)
W H D W1 W2 H1 H2 D1 t1 d
4018E
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.9
(8.6)
4023E
140
(5.51)
260
(10.24)
196
(7.72)
122
(4.80)
9
(0.35)
248
(9.76)
6
(0.24)
55
(2.17)
5
(0.20)
M5
3.9
(8.6)
4031E
180
(7.09)
300
(11.81)
196
(7.72)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
5.5
(12.1)
4038E
180
(7.09)
300
(11.81)
196
(7.72)
160
(6.30)
10
(0.39)
284
(11.18)
8
(0.31)
55
(2.17)
5
(0.20)
M5
5.5
(12.1)
4044E
190
(7.48)
350
(13.78)
251
(9.88)
160
(6.30)
15
(0.59)
336
(13.23)
7
(0.28)
94
(3.70)
5
(0.20)
M6
8.0
(17.6)
4060E
190
(7.48)
350
(13.78)
251
(9.88)
160
(6.30)
15
(0.59)
336
(13.23)
7
(0.28)
94
(3.70)
5
(0.20)
M6
8.5
(18.7)
