YASKAWA CIPR-GA50CB001

2.6 Removing/Reattaching Covers
44 YASKAWA SIEPC71061753C GA500 Technical Manual
2. Use a slotted screwdriver to lock the front cover of the drive.
Use a slotted screwdriver with a tip width of 2.5 mm (0.1 in) or less and a thickness of 0.4 mm (0.02 in) or
less.
A - Front cover lock
Figure 2.10 Locking the Front Cover
