2.10 Conditions
52 YASKAWA SIEPC71061753C GA500 Technical Manual
Table 2.29 Three-Phase 200 V Class (Finless-Type Drive)
Drive Model
Rated Output Current
(A)
Carrier Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit Loss
Heatsink Plate Loss
(P
Loss
)
Total Loss
2001 0.8 10 6 5 11
2002 1.6 10 7 8 15
2004 3.0 10 10 16 26
2006 5.0 10 14 27 41
2008 6.9 8 15 35 50
2010 8.0 8 18 43 61
2012 11.0 8 24 56 80
2018 14.0 8 30 82 112
2021 17.6 8 40 108 148
2030 25.0 8
50 163 214
2042 33.0 8
73 212 285
2056 47.0 8
108 347 455
2070 60.0 8
171 455 626
Table 2.30 Three-Phase 400 V Class (Finless-Type Drive)
Drive Model
Rated Output Current
(A)
Carrier Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit Loss
Heatsink Plate Loss
(P
Loss
)
Total Loss
4001 1.2 8 9 11 20
4002 1.8 8 11 16 27
4004 3.4 8 15 31 46
4005 4.8 8 18 42 60
4007 5.6 8 18 49 67
4009 7.3 8 25 65 90
4012 9.2 8 32 85 117
4018 14.8 8
52 149 201
4023 18 8
92 207 299
4031 24 8
75 240 315
4038 31 8
108 319 427
■ Normal Duty Rating (ND)
Table 2.31 Single-Phase 200 V Class (Finless-Type Drive)
Drive Model
Rated Output Current
(A)
Carrier Frequency
(kHz)
Drive Watt Loss (W)
Interior Unit Loss
Heatsink Plate Loss
(P
Loss
)
Total Loss
B001 1.2 2 8 6 14
B002 1.9 2 14 11 25
B004 3.5 2 14 17 31
B006 6.0 2 17 26 43
B010 9.6 2 36 50 86
B012 12.2 2 48 60 108
