Parameter Details
12
12.12 T: Auto-Tuning
YASKAWA SIEPC71061753C GA500 Technical Manual 781
■ T2-05: PM Motor Rated Voltage
No.
(Hex.)
Name Description
Default
(Range)
T2-05
(0732)
PM Motor Rated Voltage
Sets the rated voltage (V) of the motor.
200 V Class: 200.0 V,
400 V Class: 400.0 V
(200 V Class: 0.0 - 255.0 V,
400 V Class: 0.0 - 510.0 V)
■ T2-06: PM Motor Rated Current
No.
(Hex.)
Name Description
Default
(Range)
T2-06
(0733)
PM Motor Rated Current
Sets the rated current (A) of the motor.
Determined by o2-04
(10% to 200% of the drive
rated current)
■ T2-07: PM Motor Base Frequency
No.
(Hex.)
Name Description
Default
(Range)
T2-07
(0753)
PM Motor Base Frequency
Sets the base frequency (Hz) of the motor.
87.5 Hz
(0.0 - 590.0 Hz)
■ T2-08: Number of PM Motor Poles
No.
(Hex.)
Name Description
Default
(Range)
T2-08
(0734)
Number of PM Motor Poles
Sets the number of motor poles.
6
(2 - 120)
■ T2-09: PM Motor Base Speed
No.
(Hex.)
Name Description
Default
(Range)
T2-09
(0731)
PM Motor Base Speed
Sets the motor base speed (min
-1
(r/min)).
1750 min
-1
(r/min)
(0 - 34500 min
-1
(r/min))
■ T2-10: PM Motor Stator Resistance
No.
(Hex.)
Name Description
Default
(Range)
T2-10
(0754)
PM Motor Stator Resistance
Sets the stator resistance for each motor phase.
Determined by T2-02
(0.000 - 65.000 Ω)
Note:
This parameter does not set line-to-line resistance.
■ T2-11: PM Motor d-Axis Inductance
No.
(Hex.)
Name Description
Default
(Range)
T2-11
(0735)
PM Motor d-Axis
Inductance
Sets the d-axis inductance of the motor on a per phase basis.
Determined by T2-02
(0.00 - 600.00 mH)
■ T2-12: PM Motor q-Axis Inductance
No.
(Hex.)
Name Description
Default
(Range)
T2-12
(0736)
PM Motor q-Axis
Inductance
Sets the q-Axis inductance of the motor on a per phase basis.
Determined by T2-02
(0.00 - 600.00 mH)
