No. Name Setting Range Default
P9-07 Lag Fixed Speed Delay 0 to 1000 s 5 s
n
P9-08: Add Pump Mode
Selects the detection method for staging a new pump.
No. Name Setting Range Default
P9-08 Add Pump Mode 0 to 3 2
Setting 0: Output frequency
Setting 1: Feedback
Setting 2: Feedback + Fout
Setting 3: Flow meter
n
P9-09: Add Frequency Level
Sets the level above which the output frequency must rise for the time set in P9-11 for the lead drive to request a new lead
drive through the iQpump Modbus network when P9-08 is set to 0.
When P9-08 is set to 2, the delta feedback (setpoint – feedback) must also exceed the level set in P9-10.
No. Name Setting Range Default
P9-09 Add Frequency Level 0.0 to 400.0 Hz 59.5 Hz
n
P9-10: Add Delta Level
Sets the level above which the delta feedback (setpoint – feedback) for the time set in P9-11 for the lead drive to request a
new lead drive through the iQpump Modbus network when P9-08 is set to 1.
When P9-08 is set to 2, the output frequency must also exceed the level set in P9-09.
No. Name Setting Range Default
P9-10 Add Delta Level 0.0 to 6000.0 4.0 PSI
n
P9-11: Add Delay Time
Sets the delay time before a new lead drive is added to the system.
No. Name Setting Range Default
P9-11 Add Delay Time 0 to 3600 s 10 s
n
P9-12: Remove Pump Mode
Selects the detection method for de-staging to the previous lead pump.
No. Name Setting Range Default
P9-12 Remove Pump Mode 0 to 3 0
Setting 0: Output frequency
Setting 1: Feedback
Setting 2: Feedback + Fout
Setting 3: Flow meter
n
P9-13: Remove Frequency Level
Sets the level below which the output frequency must fall for the time set in P9-15 for the lead drive to request to be removed
from the system through the iQpump Modbus network when P9-12 is set to 0.
When P9-12 is set to 2, the delta feedback (feedback – setpoint) must also exceeded the level set in P9-14.
No. Name Setting Range Default
P9-13 Remove Frequency Level 0.0 to 400.0 Hz 40.0 Hz
n
P9-14: Remove Delta Level
Sets the level above which the delta feedback (setpoint – feedback) must rise for the time set in P9-15 for the lead drive to
request to be removed from the system through the iQpump Modbus network when P9-12 is set to 1.
5.11 P: Pump
