LED Display LCD Display Error Name
Settings for N.C. and N.O. input for the
following functions were selected
simultaneously:
• External Search Command 1 and External
Search Command 2 (61 vs. 62)
• Fast Stop N.O. and Fast Stop N.C. (15 vs.
17)
• KEB Command 1 and KEB Command 2
(65, 66 vs. 7A, 7B)
• FWD Run Command (or REV) and FWD/
REV Run Command (2-wire) (40, 41 vs.
42, 43)
• External DB Command and Drive Enable
(60 vs. 6A)
• Check if contradictory settings have simultaneously been assigned to the multi-function input terminals.
• Correct setting errors.
One of the following settings was entered
while H1-oo = 2 (External Reference 1/2):
• b1-15 = 4 (Pulse Train Input) but the pulse
train input selection is not set for the
frequency reference (H6-01 > 0)
• b1-15 or b1-16 set to 3 but no option card
is connected
• Although b1-15 = 1 (Analog Input) and
H3-02 or H3-10 are set to 0 (Frequency
Bias)
Correct the settings for the multi-function input terminal parameters.
H2-oo is set to 38 (Drive Enabled) and H1-
oo is not set to 6A (Drive Enable).
LED Display LCD Display Error Name
ope04
oPE04
Initialization Required, Term <–> Ctrl Chg
Cause Possible Solutions
The drive, control board, or terminal board
have been replaced and the parameter
settings between the control board and the
terminal board no longer match.
• Set A1-03 to 5550 to load the parameter settings stored in the terminal board to the drive.
• Initialize parameters after drive replacement by setting A1-03 to 1110 or 2220.
LED Display LCD Display Error Name
ope05
oPE05
Run Command/Frequency Reference Source Selection Error
Cause Possible Solutions
Frequency reference is assigned to an option
card (b1-01 = 3) and an input option card is
not connected to the drive.
Reconnect the input option card to the drive.
The Run command is assigned to an option
card (b1-02 = 3) and an input option card is
not connected to the drive.
Frequency reference is assigned to the pulse
train input (b1-01 = 4) and terminal RP is not
set for frequency reference input (H6-01 > 0)
Set H6-01 to 0.
LED Display LCD Display Error Name
ope07
oPE07
Multi-Function Analog Input Selection Error
A contradictory setting is assigned to multi-function analog inputs H3-02 or H3-10 and PID functions
conflict.
Cause Possible Solutions
H3-02 and H3-10 are set to the same value.
Change the settings to H3-02 or H3-10 so that functions no longer conflict.
Note: Both 0 (Frequency Reference Bias) and F (Not Used) can be set to H3-02 or H3-10
simultaneously.
6.5 Operator Programming Errors
