Three-Phase 200 V Class Drives

Table A.2 Three-Phase 200 V Class Power Ratings

Item Specification

Three-Phase Drive Model 2V0006 2V0010 2V0012 2V0020

Maximum Motor Size Allowed kW (HP)

<1>

1.1 (1.5) 2.2 (3) 3.0 (3) 5.5 (5)

Input

Input Current (A)

<2>

7.3 10.8 13.9 24.0

Output

Rated Output Capacity (kVA)

<3>

2.3 3.7 4.6 7.5

Output Current (A) 6.0 9.6 12.0 19.6

Overload Tolerance

120% of rated output current for 1 minute

(Derating may be required for applications that start and stop frequently)

Carrier Frequency User-adjustable 2 to 15 kHz

Max Output Voltage (V)

Three-phase power: 200 to 240 V

(proportional to input voltage)

Max Output Frequency (Hz) 400 Hz (user-adjustable)

Power Supply

Rated Voltage

Rated Frequency

Three-phase power: 200 to 240 V 50/60 Hz

DC power supply: 270 to 340 V

<4>

Allowable Voltage Fluctuation -15 to 10%

Allowable Frequency

Fluctuation

±5%

Harmonic Corrective

Actions

DC Link Choke Optional

<1> The motor capacity (HP) refers to a NEC rated 4-pole motor. The rated output current of the drive output amps should be equal to or greater than

the motor rated current.

<2> Input current rating varies depending on the power supply transformer, input reactor, wiring connections, and power supply impedance.

<3> Rated motor capacity is calculated with a rated output voltage of 230 V.

<4> DC is not available for UL standards.

Table A.3 Three-Phase 200 V Class Power Ratings Continued
