Three-Phase 400 V Class Drives
Table A.4 Three-Phase 400 V Class Power Ratings
Item Specification
Three-Phase Model 4V0002 4V0004 4V0005 4V0007 4V0009
Maximum Applicable Motor Capacity kW (HP)
<1>
0.75 (1.0) 1.5 (2) 2.2 (3) 3.0 (3) 3.7 (5)
Input
Input Current (A)
<2>
2.1 4.3 5.9 8.1 9.4
Output
Rated Output Capacity (kVA)
<3>
1.6 3.1 4.1 5.3 6.7
Output Current (A) 2.1 4.1 5.4 6.9 8.8
Overload Tolerance
120% of rated output current for 60 s
(Derating may be required for applications that start and stop frequently)
Carrier Frequency User-adjustable 2 to 15 kHz
Max Output Voltage (V) Three-phase power: 380 to 480 V (proportional to input voltage)
Max Output Frequency (Hz) 400 Hz (user-adjustable)
Power Supply
Rated Voltage
Rated Frequency
Three-phase power: 380 to 480 V 50/60 Hz
DC power supply: 510 to 680 V
<4>
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency
Fluctuation
±5%
Harmonic Corrective
Actions
DC Link Choke Optional
<1> The motor capacity (HP) refers to a NEC 4-pole motor. The rated output current of the drive output amps should be equal to or greater than the
motor rated current.
<2> Input current rating varies depending on the power supply transformer, input reactor, wiring conditions, and power supply impedance.
<3> Rated motor capacity is calculated with a rated output voltage of 460 V.
<4> DC is not available for UL standards.
Table A.5 Three-Phase 400 V Class Power Ratings Continued
Item Specification
Three-Phase Model 4V0011 4V0018 4V0023 4V0031 4V0038
Maximum Applicable Motor Capacity kW (HP)
<1>
5.5 (7.5) 7.5 (10) 11 (15) 15 (20) 18.5 (25)
Input
Input Current (A)
<2>
14.0 20.0 24.0 38.0 44.0
Output
Rated Output Capacity (kVA)
<3>
8.5 13.3 17.5 23.6 29.0
Output Current (A) 11.1 17.5 23.0 31.0 38.0
Overload Tolerance
120% of rated output current for 60 s
(Derating may be required for applications that start and stop frequently)
Carrier Frequency User-adjustable 2 to 15 kHz
Max Output Voltage (V) Three-phase power: 380 to 480 V (proportional to input voltage)
Max Output Frequency (Hz) 400 Hz (user-adjustable)
Power Supply
Rated Voltage
Rated Frequency
Three-phase power: 380 to 480 V 50/60 Hz
DC power supply: 510 to 680 V
<4>
Allowable Voltage Fluctuation -15 to 10%
Allowable Frequency Fluctuation ±5%
Harmonic Corrective
Actions
DC Link Choke Optional
<1> The motor capacity (HP) refers to a NEC 4-pole motor. The rated output current of the drive output amps should be equal to or greater than the
motor rated current.
<2> Input current rating varies depending on the power supply transformer, input reactor, wiring conditions, and power supply impedance.
<3> Rated motor capacity is calculated with a rated output voltage of 460 V.
<4> DC is not available for UL standards.
A.1 Power Ratings
310
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
