YASKAWA iQpump Micro CIMR-PW Series

Table 2.4 Dimensions for IP20/NEMA 1, UL Type 1 Enclosure Drives
W1
W
H5
H2
H4
H
H3
D1
t1
D
H1
4-d
H6
Voltage
Class
Drive
Model
Dimensions mm (in)
W H
D
<1>
W1 H1 H2 H3 H4 H5 H6 D1 t1 d
Wt.
kg (lb.)
Single-
Phase
200 V
Class
2V0030F
140
(5.51)
254
(10.00)
140
(5.51)
122
(4.80)
234
(9.21)
248
(9.76)
6
(0.24)
13
(0.51)
13
(0.51)
1.5
(0.06)
55
(2.17)
5
(0.20)
M5
3.8
(8.4)
2V0040F
140
(5.51)
254
(10.00)
140
(5.51)
122
(4.80)
234
(9.21)
248
(9.76)
6
(0.24)
13
(0.51)
13
(0.51)
1.5
(0.06)
55
(2.17)
5
(0.20)
M5
3.8
(8.4)
2V0056F
180
(7.09)
290
(11.42)
163
(6.42)
160
(6.30)
270
(10.63)
284
(11.18
)
6
(0.24)
15
(0.59)
13
(0.51)
1.5
(0.06)
75
(2.95)
5
(0.20)
M5
5.5
(12.1)
2V0069F
220
(8.66)
350
(13.78)
187
(7.36)
192
(7.56)
320
(12.60)
336
(13.23
)
7
(0.28)
15
(0.59)
22
(0.87)
1.5
(0.06)
78
(3.07)
5
(0.20)
M6
9.2
(20.3)
Three-
Phase
200 V
Class
4V0018F
140
(5.51)
254
(10.00)
140
(5.51)
122
(4.80)
234
(9.21)
248
(9.76)
6
(0.24)
13
(0.51)
13
(0.51)
1.5
(0.06)
55
(2.17)
5
(0.20)
M5
3.8
(8.4)
4V0023F
140
(5.51)
254
(10.00)
140
(5.51)
122
(4.80)
234
(9.21)
248
(9.76)
6
(0.24)
13
(0.51)
13
(0.51)
1.5
(0.06)
55
(2.17)
5
(0.20)
M5
3.8
(8.4)
4V0031F
180
(7.09)
290
(11.42)
143
(5.63)
160
(6.30)
270
(10.63)
284
(11.18
)
6
(0.24)
15
(0.59)
13
(0.51)
1.5
(0.06)
55
(2.17)
5
(0.20)
M5
5.2
(11.5)
Three-
Phase
400 V
Class
4V0038F
180
(7.09)
290
(11.42)
163
(6.42)
160
(6.30)
270
(10.63)
284
(11.18
)
6
(0.24)
13
(0.51)
13
(0.51)
1.5
(0.06)
75
(2.95)
5
(0.20)
M5
5.5
(12.1)
<1> The installed 24 V power supply option adds 27 mm (1.06 in.) to the total depth of the drive.
2.2 Mechanical Installation
32
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
