YASKAWA iQpump Micro CIMR-PW Series

Table 2.3 Dimensions for IP20/NEMA 1, UL Type 1 Enclosure Drives
H6
4-M4
W1
W
H5 H2
H4
HH3
D1
D
H1
t1
Voltage
Class
Drive Model
Dimensions mm (in)
W H
D
<1>
W1 H1 H2 H3 H4 H5 H6 D1 t1
Wt.
kg (lb.)
Single-
Phase
200 V Class
BV0006F
108
(4.25)
149.5
(5.89)
137.5
(5.41)
96
(3.78)
128
(5.03)
118
(4.65)
4
(0.16)
20
(0.79)
5
(0.20)
1.5
(0.06)
58
(2.28)
5
(0.20)
1.9
(4.2)
BV0010F
108
(4.25)
149.5
(5.89)
154
(6.06)
96
(3.78)
128
(5.03)
118
(4.65)
4
(0.16)
20
(0.79)
5
(0.20)
1.5
(0.06)
58
(2.28)
5
(0.20)
2.0
(4.4)
BV0012F
140
(5.51)
153
(6.02)
163
(6.42)
128
(5.04)
128
(5.03)
118
(4.65)
4.8
(0.19)
20
(0.79)
5
(0.20)
5
(0.20)
65
(2.56)
5
(0.20)
2.6
(5.7)
BV0018F
170
(6.69)
171
(6.73)
180
(7.08)
158
(6.22)
133
(5.23)
118
(4.64)
4.8
(0.19)
38
(1.50)
5
(0.20)
5
(0.20)
65
(2.56)
5
(0.20)
3.3
7.3
Three-
Phase
200 V Class
2V0010F
108
(4.25)
149.5
(5.89)
129
(5.08)
96
(3.78)
128
(5.03)
118
(4.65)
4
(0.16)
20
(0.79)
5
(0.20)
1.5
(0.06)
58
(2.28)
5
(0.20)
1.9
(4.2)
2V0012F
108
(4.25)
149.5
(5.89)
137.5
(5.41)
96
(3.78)
128
(5.03)
118
(4.65)
4
(0.16)
20
(0.79)
5
(0.20)
1.5
(0.06)
58
(2.28)
5
(0.20)
1.9
(4.2)
2V0020F
140
(5.51)
153
(6.02)
143
(5.63)
128
(5.04)
128
(5.03)
118
(4.65)
4.8
(0.19)
20
(0.79)
5
(0.20)
5
(0.20)
65
(2.56)
5
(0.20)
2.6
(5.7)
Three-
Phase
400 V Class
4V0002F
108
(4.25)
149.5
(5.89)
99
(3.90)
96
(3.78)
128
(5.03)
118
(4.65)
4
(0.16)
20
(0.79)
5
(0.20)
1.5
(0.06)
28
(1.10)
5
(0.20)
1.4
(3.1)
4V0004F
108
(4.25)
149.5
(5.89)
137.5
(5.41)
96
(3.78)
128
(5.03)
118
(4.65)
4
(0.16)
20
(0.79)
5
(0.20)
1.5
(0.06)
58
(2.28)
5
(0.20)
1.9
(4.2)
4V0005F
108
(4.25)
149.5
(5.89)
154
(6.06)
96
(3.78)
128
(5.03)
118
(4.65)
4
(0.16)
20
(0.79)
5
(0.20)
1.5
(0.06)
58
(2.28)
5
(0.20)
1.9
(4.2)
4V0007F
108
(4.25)
149.5
(5.89)
154
(6.06)
96
(3.78)
128
(5.03)
118
(4.65)
4
(0.16)
20
(0.79)
5
(0.20)
1.5
(0.06)
58
(2.28)
5
(0.20)
1.9
(4.2)
4V0009F
108
(4.25)
149.5
(5.89)
154
(6.06)
96
(3.78)
128
(5.03)
118
(4.65)
4
(0.16)
20
(0.79)
5
(0.20)
1.5
(0.06)
58
(2.28)
5
(0.20)
1.9
(4.2)
4V0011F
140
(5.51)
153
(6.02)
143
(5.63)
128
(5.04)
128
(5.03)
118
(4.65)
4.8
(0.19)
20
(0.79)
5
(0.20)
5
(0.20)
65
(2.56)
5
(0.20)
2.6
(5.7)
<1> The installed 24 V power supply option adds 27 mm (1.06 in.) to the total depth of the drive.
2.2 Mechanical Installation
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
31
2
Mechanical Installation
