Table D.3 Three-Phase 200 V Class Fuses and Fuse Holders
Drive Model
DC Power Supply Input
Fuse Fuse Holder
Manufacturer: Fuji Electric
Type
Rated Short Circuit
Braking Current
(kA)
Qty. Type Qty.
2A0001 CR6L-20/UL
100 2
CMS-4
2
2A0002 CR6L-20/UL CMS-4
2A0004 CR6L-20/UL CMS-4
2A0006 CR6L-30/UL CMS-4
2A0010 CR6L-50/UL CMS-4
2A0012 CR6L-50/UL CMS-4
2A0020 CR6L-75/UL CMS–5
Table D.4 Three-Phase 400 V Class Fuses and Fuse Holders
Drive Model
DC Power Supply Input
Fuse Fuse Holder
Manufacturer: Fuji Electric
Type
Rated Short Circuit
Braking Current
(kA)
Qty. Type Qty.
4A0001 CR6L-20/UL
100 2
CMS-4
2
4A0002 CR6L-20/UL CMS-4
4A0004 CR6L-50/UL CMS-4
4A0005 CR6L-50/UL CMS-4
4A0007 CR6L-50/UL CMS-4
4A0009 CR6L-50/UL CMS-4
4A0011 CR6L-50/UL CMS-4
n
Guarding Against Harmful Materials
When installing IP20/Open-Chassis enclosure drives, use an enclosure that prevents foreign material from entering the drive
from above or below.
u
EMC Guidelines Compliance
This drive is tested according to European standards EN 61800-3:2004/A1:2012 and it complies with the EMC guidelines.
n
EMC Filter Installation
The following conditions must be met to ensure continued compliance with guidelines.
Refer to EMC Filters on page 425
for EMC filter selection.
Installation Method
Verify the following installation conditions to ensure that other devices and machinery used in combination with this drive
also comply with EMC guidelines.
1.
Install an EMC noise filter to the input side specified by Yaskawa for compliance with European standards.
2.
Place the drive and EMC noise filter in the same enclosure.
3.
Use braided shield cable for the drive and motor wiring or run the wiring through a metal conduit.
4.
Keep wiring as short as possible. Ground the shield on both the drive side and the motor side.
5.
Ground the largest possible surface area of the shield to the metal conduit when using braided shield cable. Yaskawa
recommends using a cable clamp.
D.2 European Standards
