YASKAWA iQpump Micro CIMR-PW Series

Drive
Model
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
BA0018
R/L1, S/L2, T/L3 8 12 to 8
M5
2.3 to 2.5
(20.4 to 22.1)
U/T1, V/T2, W/T3 10 12 to 8
, 1, 2
– 12 to 8
B1, B2 – 12 to 8
8 12 to 8
2 to 2.5
(17.7 to 22.1)
Table D.7 Wire Gauge and Torque Specifications
Drive
Model
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
2A0001
2A0002
2A0004
2A0006
R/L1, S/L2, T/L3 14 18 to 14
M3.5
0.8 to 1.0
(7.1 to 8.9)
U/T1, V/T2, W/T3 14 18 to 14
, 1, 2
– 18 to 14
B1, B2 – 18 to 14
14 18 to 14
2A0010
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
2A0012
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
2A0020
R/L1, S/L2, T/L3 10 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 10 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
2A0030
R/L1, S/L2, T/L3 8 10 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 8 10 to 6
, 1, 2
– 10 to 6
B1, B2 – 14 to 10
8
<1>
10 to 6 M5
2 to 2.5
(17.7 to 22.1)
2A0040
R/L1, S/L2, T/L3 6 10 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 8 10 to 6
–, +1, +2 – 10 to 6
B1, B2 – 14 to 10
6 10 to 6 M5
2 to 2.5
(17.7 to 22.1)
2A0056
R/L1, S/L2, T/L3 4 6 to 4
M6
5.4 to 6.0
(47.8 to 53.1)
U/T1, V/T2, W/T3 4 6 to 4
, 1, 2
– 6 to 4
B1, B2 – 10 to 6 M5
2.7 to 3.0
(23.9 to 26.6)
6 8 to 4 M6
5.4 to 6.0
(47.8 to 53.1)
