YASKAWA iQpump Micro CIMR-PW Series

Drive
Model
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
2A0069
R/L1, S/L2, T/L3 3 8 to 2
M8
9.9 to 11
(87.6 to 97.4)
U/T1, V/T2, W/T3 3 8 to 2
, 1, 2
– 8 to 2
B1, B2 – 8 to 6 M5
2.7 to 3.0
(23.9 to 26.6)
6 6 to 4 M6
5.4 to 6.0
(47.8 to 53.1)
<1> When an EMC filter is installed, additional measures must be taken to comply with IEC/EN 61800-5-1. Refer to EMC Filter Installation on page
424 for details.
Table D.8 Wire Gauge and Torque Specifications
Drive
Model
Terminal
Recomm.
Gauge
AWG, kcmil
Wire Range
AWG, kcmil
Screw
Size
Tightening
Torque
N•m (lb.in.)
4A0001
4A0002
4A0004
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
14 14 to 10
4A0005
4A0007
4A0009
R/L1, S/L2, T/L3 14 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
4A0011
R/L1, S/L2, T/L3 12 14 to 10
M4
1.2 to 1.5
(10.6 to 13.3)
U/T1, V/T2, W/T3 14 14 to 10
, 1, 2
– 14 to 10
B1, B2 – 14 to 10
10 14 to 10
4A0018
R/L1, S/L2, T/L3 10 14 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 10 14 to 6
, 1, 2
– 14 to 6
B1, B2 – 14 to 10
8 14 to 6 M5
2 to 2.5
(17.7 to 22.1)
4A0023
R/L1, S/L2, T/L3 10 10 to 6
M4
2.1 to 2.3
(18.6 to 20.4)
U/T1, V/T2, W/T3 10 10 to 6
, 1, 2
– 10 to 6
B1, B2 – 14 to 10
8 10 to 6 M5
2 to 2.5
(17.7 to 22.1)
4A0031
R/L1, S/L2, T/L3 8 10 to 6
M5
3.6 to 4.0
(31.8 to 35.4)
U/T1, V/T2, W/T3 8 10 to 6
, 1, 2
– 10 to 6
B1, B2 – 14 to 10
2.7 to 3.0
(23.9 to 26.6)
6
<1>
10 to 6 M6
5.4 to 6.0
(47.8 to 53.1)
D.3 UL and CSA Standards
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
429
