• Semiconductor fuses.
• Molded Case Circuit Breakers (MCCB).
Table D.10 Factory Recommended Drive Branch Circuit Protection
Drive Model
Non-time Delay
Fuse Rating (A)
<1>
Time Delay Fuses
Bussmann
Semiconductor
Fuse Part Number
(Fuse Ampere)
<4>
MCCB
<5>
Class J, T, or CC
Fuse Rating (A)
<2>
Class RK5
Fuse Rating (A)
<3>
Rating (A)
Minimum
Enclosure
Volume (in
3
)
200 V Class Single-Phase Drives
BA0001 6 3.5 4 FWH-25A14F (25) 15 600
BA0002 10 6 8 FWH-25A14F (25) 15 600
BA0003 20 10 15 FWH-60B (60) 15 600
BA0006 40 20 30 FWH-80B (80) 30 1152
BA0010 40 35 45 FWH-100B (100) 50 1152
200 V Class Three-Phase Drives
2A0001 3 1.5 2 FWH-25A14F (25) 15 600
2A0002
6
<6>
3 3 FWH-25A14F (25) 15 600
2A0004
15
<7>
6 8 FWH-25A14F (25) 15 600
2A0006 20 10 15 FWH-25A14F (25) 15 1152
2A0010 25 15 20 FWH-70B (70) 25 1152
2A0012 25 20 30 FWH-70B (70) 30 1152
2A0020 40 40 50 FWH-90B (90) 60 1152
400 V Class Three-Phase Drives
4A0001 3 2 2 FWH-40B (40) 15 1152
4A0002 6 3.5 3 FWH-40B (40) 15 1152
4A0004
15
<7>
7 8 FWH-50B (50) 15 1152
4A0005
20
<8>
10 10 FWH-70B (70) 15 1152
4A0007
25
<9>
12 15 FWH-70B (70) 20 1152
4A0009 25 15 20 FWH-90B (90) 20 1152
4A0011 30 20 30 FWH-90B (90) 35 1152
<1> Maximum 300% of drive input current rating for any Class J, T, or CC fuse except for models 2A0002, 2A0004, 4A0004, 4A0005, and 4A0007.
<2> Maximum 175% of drive input current rating for any Class J, T, or CC fuse.
<3> Maximum 225% of drive input current rating for any Class RK5 fuse.
<4> When using semiconductor fuses, Bussmann FWH are required for UL compliance.
<5> Maximum MCCB Rating is 15 A or 200% of drive input current rating, whichever is larger. MCCB voltage rating must be 600 Vac or greater.
Additionally, when using MCCBs for protection, the drive must be installed in a ventilated enclosure with minimum volume according the “Minimum
Enclosure Volume” column.
<6> Model 2A0002 requires Mersen (Ferraz) part number A6T6 for compliance.
<7> Models 2A0004 and 4A0004 require Mersen (Ferraz) part number A6T15 for compliance.
<8> Model 4A0005 requires Mersen (Ferraz) part number A6T20 for compliance.
<9> Model 4A0007 requires Mersen (Ferraz) part number A6T25 for compliance.
n
Low Voltage Wiring for Control Circuit Terminals
Wire low voltage wires with NEC Class 1 circuit conductors. Refer to national state or local codes for wiring. The external
power supply shall be a UL-Listed Class 2 power source or equivalent.
n
Drive Short-Circuit Rating
This drive has undergone the UL short-circuit test, which certifies that during a short circuit in the power supply the current
flow will not rise above 31,000 amps maximum at 240 V for 200 V class drives and 480 V for 400 V class drives.
• The MCCB and breaker protection and fuse ratings shall be equal to or greater than the short-circuit tolerance of the power
supply being used.
• Suitable for use on a circuit capable of delivering not more than 31,000 RMS symmetrical amperes for 240 V in 200 V class
drives (up to 480 V for 400 V class drives) motor overload protection.
D.3 UL and CSA Standards
YASKAWA TOEP YAIQPM 03B YASKAWA AC Drive - iQpump Micro User Manual
431
D
Standards Compliance
