Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
Table B-6: RM2-755 Drive Assembly, MH555 Headstock with Motomount
ITEM PART
NUMBER
DESCRIPTION
QTY
163892-1 DRIVE ASSY,MH555 HEADSTOCK,W/MOTOMOUNT
1 163838-1 HOUSING, HEADSTOCK, TOOLING DRIVE
1
2 163879-1 PLATE, FACE, TOOLING DRIVE W/MOTOMOUNT
1
3 164116-1 BLOCK ASSY, HEADSTOCK, MOTOMOUNT
1
4 132616-3 SCREW,HHC,M8 X 16
2
5 470617-1 WASHER,CONICAL SPRING,GTS8
22
6 164485-1 BRUSH ASSY, GROUND, MTG BRKT, 3 POS
1
7 151594-5 REDUCER, RV, RV-80E
1
8 407248-7 SCREW, SHC, M8 X 30, CLASS 12.9
16
9 130425-2 SCREW, BHSC, M6 X 10
2
10 470602-1 WASHER, CONICAL, SPRING, GTS6, YS
3
11 156009-3 MOTOR, AC SERVO, 1.3kW, SIGMA 5
1
12 133963-3 BOLT,EYE,M10,DIN 580
2
13 146123-1 SEAL KIT, RV80E
1
14 166944-1 GEAR,INPUT,GEAR REDUCER,RV80E-153
1
15 133937-3 FITTING,ZERK M6 X 1
1
16 407249-20 SCREW,SHC,M6X65,CLASS 12.9
1
17 479297-4 SCREW, SHC, M10x1.5 X 25, CLASS 12.9
6
18 407248-6 SCREW,SHC,M8X25,CLASS 12.9,
16
19 132616-1 SCREW, HHC, M8x1.25 X 20, ZC, CLASS 8.8
1
20 479148-5 WASHER,LOCK,M8,
1
21 479147-5 WASHER,FLAT,M8,ZP,
1
22 133984-1 NAMEPLATE, GROUND
1
24 145896-6 PIN, HOMING
1
25 164530-1 LABEL, PRODUCT IDENTIFICATION, SINGLE AXIS POSITIONER
1
26 168961-1CD MANUAL,DR ASSY,HS TOOLING, W/MOTOMOUNT,
MH185,555,1655,DX200
1
27 130887-11 CABLE,WELD,4/0,1FT
2
28 180544-1 LABEL,GREASE,MOLY-WHITE RE 00
1
