YASKAWA RM2-755/1255SL User Manual

B-16
166006-1CD
166006-1CD
Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
Table B-5: Major Assemblies — RM2-755SL with MultiPort Lubricator
ITEM NO. RM2-755SL PART NUMBERS DESCRIPTION QTY
2.0M 3.0M 2.0M 3.0M
184301-1 184302-1
POSITIONER ASSY,RM2-
755SL,W/LUBE,W/O
SWITCHES,SLIP-RINGS,AND AIR
1
184299-1
HOUSING ASSY,HEADSTOCK
COLUMN,W/LUBE,RM2-755SL
1
2
163892-1
DRIVE ASSY,MH555
HEADSTOCK, W/MOTOMOUNT
2
3 164218-1 164218-3 BEAM,Z-SPREADER 1
4 163900-1 ARM ASSY, SWING, TAILSTOCK 1
5 163887-1 HOUSING, COLUMN, TAILSTOCK 1
6
184300-1
ARM ASSY,SWING,HEADSTOCK
MAIN DRIVE W/LUBE,RM2-755SL
1
7 149053-1 LABEL,A/B,POSITIONER SIDE, 2
8 149053-3 LABEL, POSITIONER, S2 1
9 149053-4 LABEL, S3 1
10 149053-2 LABEL, POSITIONER, S1 1
11
148102-4
SCREW_SHC_M6X16_JIS
0209_W/CAPTIVE LOCK &
FLAT_BLACK
17
12
175284-1
COVER,Z-BEAM,END,LH,W/
STUDS,RM2-755/1255SL
1
13
148102-5
SCREW, SHC, M6X20, W/
CAPTIVE FLAT & LOCK WASHER
18 58
14
166426-2 166426-3
SHIELD, ARC, Z-BEAM, 2057mm,
RM2-755/1255SL
2
15
175287-1
COVER,Z-BEAM,END,RH,W/
STUDS,RM2-755/1255SL
1
16
166721-1
COVER, CABLES, TAILSTOCK
SWINGARM, RM2-755/1255SL
2
17 152364-2 SCREW, HHC, M5 X 12 12
18 143047-7 PLATE,GLAND,XRC/MRC,BLANK 4
19
152310-5
PLATE, GLAND, SPLIT FOAM,
XRC/NX/DX,12MM CBL, 25X48
PASS-THRU,ZINC PLATE
3
20
137146-3
SCREW, PPH, M4 X 10, JIS B
1188,W/CAPTIVE LOCK &FLAT
WASHER
16
21
131275-4
SCREW,HHC,M20X55,ZP,CLASS
8.8
8
22
180047-1
PLATE,STRIKER,LEVELING
SCREW
8
23
175288-1
COVER,Z-BEAM,END,
RH,SHIPPING BRKT,W/STUDS
1
96 of 145
