YASKAWA RM2-755/1255SL User Manual

B-17
166006-1CD
166006-1CD
Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
24
184215-1
COVER,Z-BEAM,END,LH,MAIN
DRIVE W/LUBE,W-STUDS,RM2-
755SL
1
25 155235-2 LABEL, PATENT IDENTIFICATION 1
26
164532-1
LABEL, PRODUCT,
IDENTIFICATION, THREE AXIS
POSITIONER
1
27 166006-1CD MANUAL, RM2-SL, DX200 1
28
169718-1
COVER, CABLES, HEADSTOCK
SWINGARM, RM2-755SL
1
29
166355-1
PIN,DOWEL,PULL,M20 x
40,HARDENED STEEL,NF
DIN7979D,M6 INTERNAL THRD
4
30
131274-4
SCREW,HHC,M16X40,ZP,CLASS
8.8
28
31
132049-1
WASHER, CONICAL SPRING,
GTS16
44
32
131274-3
SCREW, HHC, M16X35, ZP,
CLASS 8.8
4
33 479147-9 WASHER,FLAT, M16,ZP 6
34
170543-1
BRACKET, SHIPPING, FORMED,
RM2-755/1255SL
1
35 479147-7 WASHER, FLAT, M12, ZP 3
36 131272-11 SCREW, HHC, M12 X1.75x 20,LG 3
37
170544-1
BRACKET, SHIPPING, ANGLE,
RM2-755/1255SL
1
38
130532-15
SCREW, SHC,
M16X60,CLASS12.9
16
39
163783-1
PIN, DOWEL, M16 X 40, m6,
ALLOY STL
4
40 479348-2 BATTERY ASSY,ERC BACKUP 3
41 130887-9 NEGATIVE WELD CABLE, 1.4M 5
42 472303-11 SCREW,SHC,M12X60,CLASS 12.9 22
43
471075-1
WASHER, CONICAL SPRING,
GTS12, YS
22
44
184216-1
COVER,MAIN DRIVE W/
LUBE,RM2-755SL
1
45
182169-1
SWITCH,PRESSURE,75-300PSI,
1/8 NPT MALE,SPDT
1
46
182171-1
FITTING,CROSS TUBE,1/4 IN
NFPT FEMALE
1
47 184615-1 GAGE, PRESS, 0-600 PSI, 1/8 NPT 1
48
182165-1
ADAPTER,STRAIGHT TUBING,
1/4 IN
1
ITEM NO. RM2-755SL PART NUMBERS DESCRIPTION QTY
2.0M 3.0M 2.0M 3.0M
97 of 145
