Appendix B
B.1 Illustrated Parts List
RM2-755/1255SL
Positioner
70
180545-1
LABEL,GREASE,MOBIL CM-P
No. 2
1
71
471376-1
LABEL, MOVING PARTS,
HORIZONTAL
4
72
471359-1
LABEL, ROBOT WARNING,
HORIZONTAL
4
73 471378-1 LABEL,ARC FLASH,HORIZONTAL, 4
74 159257-1 LABEL,ARCWORLD, 2
75
173483-1
LABEL,YASKAWA, 110 X 675,
WHITE
2
76
472268-18
LABEL, CAPACITY, WEIGHT,
755kg
2
77 173463-1 FITTING,PLUG,37° FLARED,3/8" 2
78 145790-3 FITTING_SWIVEL_FEMALE-PIPE 5
79
145759-3
HOSE, 1/2 ID, 250 PSI, BLACK,
USE W/PUSH-LOK FITTINGS
5200
80 145789-5 FITTING,TUBE,MALE FLARE 3
81 145791-4 FITTING,TEE,FEMALE,1/2BSPT 1
82
NA 166426-1
SHIELD, ARC, Z-BEAM, 747mm,
RM2-755/1255SL
4
83
NA 175289-1
STRAP,Z-BEAM,ARC SHIELD,W/
STUDS,RM2-755/1255SL
4
ITEM NO. RM2-755SL PART NUMBERS DESCRIPTION QTY
2.0M 3.0M 2.0M 3.0M
99 of 145
