8 Adjustments
8-4
When the vibration is suppressed but overshooting occurs, increase the Q value and check whether the over-
shooting is corrected.
Change the Notch Filter Frequency (Pn409 or Pn40C) only when the motor is stopped. Vibration may occur
if the notch filter frequency is changed when the motor is rotating.
Pn40A First Stage Notch Filter Q Value
Setting Range Setting Unit Factory Setting Setting Validation
70 to 1000
(0.70 to 10.00)
0.01 70
(0.70)
Immediately
Pn40D Second Stage Notch Filter Q Value
Setting Range Setting Unit Factory Setting Setting Validation
70 to 1000
(0.70 to 10.00)
0.01 70
(0.70)
Immediately
IMPORTANT
