2.4 Selecting Cables
2-23
2
dServomotor
Main Circuit
Cable
Connectors
Without
brakes
(For small-
capacity
series)
SGMCS-

B,C,D,E
3 m
(9.84 ft)
JZSP-CMM60-03 JZSP-CSM60-03
5 m
(16.4 ft)
JZSP-CMM60-05 JZSP-CSM60-05
10 m
(32.8 ft)
JZSP-CMM60-10 JZSP-CSM60-10
15 m
(49.2 ft)
JZSP-CMM60-15 JZSP-CSM60-15
20 m
(65.5 ft)
JZSP-CMM60-20 JZSP-CSM60-20
Without
brakes
(For
middle-
capacity
series)
SGMCS-

M,N
Cables with connectors and cables/
connector are not available. Contact
your Yaskawa representative.
Servomotor end connector
JN1DS04FK1
∗2
Soldered
Cables
For
SGMCS-
B, C, D, E
5 m
(16.4 ft)
JZSP-CSM90-05 JZSP-CSM80-05
20 m (65.6 ft) max.
10 m
(32.8 ft)
JZSP-CSM90-10 JZSP-CSM80-10
15 m
(49.2 ft)
JZSP-CSM90-15 JZSP-CSM80-15
20 m
(65.5 ft)
JZSP-CSM90-20 JZSP-CSM80-20
e
Wires and
Connectors
for Relay
Encoder
Cable
Extensions
Wires and connectors for
relay encoder cable exten-
sions are available for as-
sembly by the customer.
30 m
(98.4 ft)
JZSP-CMP19-30
50 m (164 ft) max.
40 m
(131.2
ft)
JZSP-CMP19-40
50 m
(164 ft)
JZSP-CMP19-50
(cont’d)
Name Length Type Specifications
Standard Type Flexible Type
∗1
* 1. Use flexible cables for movable sections such as robot arms. Refer to 5.6 Flexible
Cables.
* 2. Contact Japan Aviation Electronics Industry, Ltd.
