XIII
The grounding surfaces must be highly conductive bare metal. Remove any coats of varnish and paint.
– Ground the cable shields at both ends.
– Ground the motor of the machine.
You can find further informations in the document EZZ006543 which can be ordered at Yaskawa.
Ground clip Ground plate
