YASKAWA Varispeed E7 User Manual

Input Terminal Functions
6-57
Fig 6.38 UP/DOWN Commands Time Chart
Output frequency
Upper limit
Accelerates to
lower limit
Same
frequency
Lower limit
Forward operation/stop
UP command
DOWN command
Speed agree*
Reference
frequency reset
Power supply
* The speed agree signal turns ON when the motor is not accelerating/decel-
erating while the run command is ON.
