4
-16
Start autotuning.
Error Displays during Autotuning
If the STOP Key is pressed during autotuning or a measurement error is detected, an error will be displayed
and autotuning will be canceled. Details on the error will be displayed on the Digital Operator. The fault con-
tact output and the alarm output will not operate.
Refer to Errors During Autotuning in Chapter 7 Troubleshooting for details.
Stationary Autotuning for Line-to-Line Resistance Only (T1-01 = 2)
Stationary autotuning for line-to-line resistance only can be used in any control method. This is the only auto-
tuning possible for V/f control and V/f control with PG modes.
Autotuning can be used to prevent control errors when the motor cable is long (50 m or longer) or the cable
length has changed since installation or when the motor and Inverter have different capacities.
Set T1-01 to 2, and then press the RUN Key on the Digital Operator. The Inverter will supply power to the sta-
tionary motor for approximately 20 seconds and the Motor Line-to-Line Resistance (E2-05) and cable resis-
tance will be automatically measured.
Step Digital Operator Display
1 Press the Increment Key to access the start autotuning display.
2
Press the RUN Key to start autotuning.
Autotuning will end in 1 or 2 minutes.
3
When autotuning has been completed, press the MENU Key to change
the mode.
1. Power will be supplied to the motor when stationary autotuning for line-to-line resistance is performed
even though the motor will not turn. Do not touch the motor until autotuning has been completed.
2. When performing stationary autotuning connected to a conveyor or other machine, ensure that the
holding brake is not activated during autotuning.
67$57*2$/
㼀㼡㼚㼑㻌㻼㼞㼛㼏㼑㼑㼐㼕㼚㼓
㻙㻭㻚㼀㼁㻺㻱㻙
+]$
67$57*2$/
㼀㼡㼚㼑㻌㻼㼞㼛㼏㼑㼑㼐㼕㼚㼓
㻙㻭㻚㼀㼁㻺㻱㻙
+]$
67$57*2$/
㻙㻭㻚㼀㼁㻺㻱㻙
+]$
㻾㼐㼥
㻾㼐㼥
㼀㼡㼚㼑㻌㻼㼞㼛㼏㼑㼑㼐㼕㼚㼓
㼀㼡㼚㼑㻌㻼㼞㼛㼏㼑㼑㼐㼕㼚㼓
Display when the autotuning
has been completed
㻟㻜㻑䡲䢙䢔䡪䡯
㻙㻭㻚㼀㼁㻺㻱㻙
+]$
㼀㼡㼚㼑㻌㻿㼡㼏㼏㼑㼟㼟㼒㼡㼘
