YASKAWA Varispeed G7 Series User Manual

6 -184
Peak Hold Current Monitoring Function
This function saves the peak value (effective value) of the Inverter output current and displays it on the
Digital Operator for monitoring (U1-83). The Inverter output frequency at the moment the peak current
value is saved can be also monitored (U1-84).
At trial operation, perform adjustments so that the Inverter output current is limited to 150% of the rated
current checking the constants U1-83 and U1-84 of this function.
■Related Status Monitoring Constants
* 1. Applicable for G7-Series Inverters with software versions PRG 1039 and later.
* 2. The minimum unit differs depending on the Inverter capacity. (0.01 A for Inverter of 0.4 kW to 7.5 kW, and 0.1 A for Inverter of 11 kW or more)
* 3. The setting unit can be selected in o1-03.
Related Fault Tracing Constants
The peak hold values are saved in the fault trace memory when a fault occurs.
* 1. Applicable for G7-Series Inverters with software versions PRG 1039 and later.
* 2. The minimum unit differs depending on the Inverter capacity. (0.01 A for Inverter of 0.4 kW to 7.5 kW, and 0.1 A for Inverter of 11 kW or more)
IMPORTANT
The values of peak current and output frequency during peak hold will be cleared when the Inverter stops and then starts,
or when the power is turned OFF and then ON. They will be retained while being baseblocked (stopped).
Con-
stant
Number
Name
Description
Output Signal Level
During Multi-Function
Analog Output
Min.
Unit
Control Methods
MEMO-
BUS
Regis-
ter
Display
V/f
V/f
with
PG
Open
Loop
Vec-
tor
1
Flux
Vec-
tor
Open
Loop
Vec-
tor
2
U1-83
*1
Peak hold
current
Displays the peak value of the
current during run. “Peak
Hold” refers to the moment
that the peak value is saved.
10V: Inverter rated output
current
(-10 to 10V absolute value
output)
0.01
A
*2
AA A A A7CFH
Current
PeakHold
U1-84
*1
Output
frequency
during
peak hold
Displays the frequency value
when the output current
reached its peak value.
10V: Max frequency
(-10V to 10V)
0.01
Hz
*3
AA A A A7D0H
Freq@ I
PeakHold
Con-
stant
Number
Name
Description
Output Signal
Level During
Multi-Function
Analog Output
Min.
Unit
Control Methods
MEMO-
BUS
Regis-
ter
Display
V/f
V/f
with
PG
Open
Loop
Vec-
tor
1
Flux
Vec-
tor
Open
Loop
Vec-
tor
2
U2-21
*1
Peak hold
current at
fault
Displays the peak hold current
when the last fault occurred.
(Cannot be output.)
0.01
A
*2
AA A A A7E6H
Current
PeakHold
U2-22
*1
Peak hold
output
frequency at
fault
Displays the frequency value at
the moment the current reached
its peak value when the last fault
occurred.
(Cannot be output.)
0.01
Hz
AA A A A7E7H
Freq@ I
PeakHold
