Inverter Model Numbers
The model number of the Inverter on the nameplate indicates the specification, voltage class, and maximum
motor capacity of the Inverter in alphanumeric codes.
Fig 1.2 Inverter Model Numbers
Inverter Specifications
The Inverter specifications (“SPEC”) on the nameplate indicate the voltage class, maximum motor capacity,
the protective structure, and the revision of the Inverter in alphanumeric codes.
Fig 1.3 Inverter Specifications
TERMS
Open Chassis Type (IEC IP00)
Protected so that parts of the human body cannot reach electrically charged parts from the front when the
Inverter is mounted in a control panel.
Enclosed Wall-mounted Type [IEC IP20, NEMA 1 (Type 1)]
The Inverter is structured so that the Inverter is shielded from the exterior, and can thus be mounted to the
interior wall of a standard building (not necessarily enclosed in a control panel). The protective structure con-
forms to the standards of NEMA 1 (Type 1) in the USA. The protective covers (see Fig. 1.4) are required for
an IEC IP20 or NEMA 1 (Type 1) protective structure.
CIMR - G7 A 2 0P4
Inverter
Varispeed G7
No.
A
Standard domestic model
Specification
No.
2
4
AC input, 3-phase, 200 V
AC input, 3-phase, 400 V
Voltage Class
No.
0P4
0P7
300
0.4 kW
0.75 kW
300 kW
Max. Motor Capacity
"P" indicates the decimal point.
to
to
2 0P4 1 A
No.
0
1
Open chassis (IEC IP00)
Enclosed wall-mounted [IEC IP20,
NEMA 1 (Type 1)]
Protective Structure
No.
2
4
AC input, 3-phase, 200 V
AC input, 3-phase, 400 V
Voltage Class
No.
0P4
0P7
300
0.4 kW
0.75 kW
300 kW
Max. Motor Capacity
to
"P" indicates the decimal point.
to
Design revision order
